Product Application
Multiple mosaic and LED Display beyond normal
control resolution mosaic
Project 1: Set VSP 168HD/1# as PIP mode, and divides signal to VSP 168HD/2# to VSP 168HD/5# for
cascade by using DVI matrix (DXP D0404). The split modes, including "FIELD GLYPH", "HORIZONTAL
1/4", "VERTICAL 1/4" and "IRREGULAR" can be achieved.
Project 2: VSP 168HD/1# divides signal to VSP 168HD/2# to VSP 168HD/5# for cascade by using DVI
matrix (DXP D0404).
14
Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: 00865925771197
Fax: 00865925771202
Email: sales@rgblink.com
http://www.rgblink.cn
