Page 1 IBIZA ST Owner’s manual...
Page 3 Foreword This Instruction Manual and its corresponding supplements should be read carefully to familiarise yourself with your vehicle. Besides the regular care and maintenance of the vehicle, its correct handling will help preserve its value. For safety reasons, note the information concerning accessories, modifications and part replacements. If selling the vehicle, give all of the on-board documentation to the new owner, as it should be kept with the vehicle.
Page 5: Table Of Contents
......Seat belts .......
Page 6 Table of Contents Accessories, parts replacement and Jump-starting ......modifications Towing and tow-starting .....
Page 7: Manual Structure
As this is a general manual for the IBIZA ST, some of the equipment and For the sake of the environment functions described in this manual are not included in all types or versions Texts preceded by this symbol contain relevant information concerning envi- of the model.
Page 8: Content
2. Operating instructions Information about the distribution of controls in the driver position of your vehicle, about the seat adjustment possibilities, about how to create a suit- able climate in the passenger compartment, etc. 3. Practical Tips Advice relating to the driving, caring and maintenance of your vehicle and certain problems you can solve yourself.
Page 9: Safety First
● Front airbags the vehicle, both for the driver and the passengers. The other sections of ● Side airbags in the front seat backrests, with chest and head protection the owner's manual also contain further information that you should be ●...
Page 10 – Observe traffic laws and speed limits. to your size. – Always reduce your speed as appropriate for road, traffic and – Ensure that the passenger in the central rear seat always has weather conditions. the head restraint in the correct position for use.
Page 11: Safe Driving
Safe driving WARNING When driving safety is impaired during a trip, the risk of injury and acci- dents increases.  Safety First Operating Instructions Practical Tips Technical Specifications...
Page 12: Proper Sitting Position For Occupants
⇒ f ig. steering wheel – Move the driver seat forwards or backwards so that you are able to press the accelerator, brake and clutch pedals to the floor with your knees still slightly angled ⇒ .
Page 13 ● An incorrect sitting position of the driver can lead to severe injuries. – Move the front passenger seat back as far as possible ⇒ . ● Adjust the driver seat so that there is at least 25 cm distance between ⇒ f ig.
Page 14 ● Always keep your feet in the footwell when the vehicle is moving; never rest them on the dash panel, out the window or on the seat. An in- – Keep both feet in the footwell in front of the rear seat.
Page 15 Safe driving Correct adjustment of head restraints Adjust the head restraint properly in order to achieve maximum protection. Properly adjusted head restraints are an important part of – Adjust the head restraint so that its upper edge is at the same passenger protection and can reduce the risk of injuries in level as the top of your head or as close as possible to the same most accident situations.
Page 16 Incorrect sitting positions substantially re- duce the protective function of seat belts and increase the risk of injury due to incorrect seat belt position. As the driver, you are re- Fig. 5 Adjusting the rear sponsible for all vehicle occupants, especially children.
Page 17 ● Never put your feet out of a window. ● Never put your feet on the dash panel. ● Never put your feet on the surface of a seat. ● Do not allow anyone to travel in the footwell. ● Never travel without wearing the seat belt.
Page 18: Pedal Area
Safe driving Pedal area Floor mats on the driver side Only floor mats may be used which can be securely fastened Pedals in the footwell and do not impair operation of the pedals. The operation of all pedals must never be impaired by ob- –...
Page 19 Before you lock the vehicle, make sure that there are no adults or children in the vehicle. ● Never transport passengers in the luggage compartment. All passen- gers must have their seat belt fastened ⇒ p age 19. Safety First Operating Instructions...
Page 20 ● To prevent pieces of luggage or other objects from flying forward, al- ways use appropriate retaining cords which are secured to the fastening rings. ● Never secure a child seat on the fastening rings. ...
Page 21: Seat Belts
Seat belts Brief introduction Number of seats Your vehicle has five seats, two in the front and three in the rear. Each seat Before driving: remember your seat belt! is equipped with a three-point seat belt. Wearing a seat belt properly can save your life! In some versions, your vehicle is approved only for four seats.
Page 22 25 km/h. This acoustic sig- nal stops when the seat belt is fastened. The warning lamp*  is switched off if the driver seat belt is fastened while the ignition is switched on. ...
Page 23: Why Wear Seat Belts
25 km/h to 50 km/h, for example, the kinetic energy is multiplied by four. Because the passengers in our example are not restrained by seat belts, in the case of a head-on collision all of their kinetic energy has to be absorbed ⇒ ...
Page 24 All occupants (including the driver) must ing a seat belt is thrown wear seat belts properly during the trip. This will reduce the risk of severe forward violently. injuries in the event of an accident – regardless of whether an airbag is fit- ted for the seat or not.
Page 25 Our examples describe frontal collisions. Of course, properly worn seat belts substantially reduce the risk of injury in all other types of accidents. This is why it is so important to fasten seat belts before every trip, even when "just driving around the corner".
Page 26 ● The belts must be kept clean, otherwise the retractors may not work ● Keep both feet in the footwell in front of your seat as long as the vehi- properly. ...
Page 27: Seat Belts
● Never put the latch plate in the buckle of another seat. If you do this, the seat belt will not protect you properly and the risk of injury is in- creased.
Page 28 The seat belt must lie flat and snugly on the torso ● The lap part of the seat belt must lie across the pelvis, never across the stomach. The seat belt must lie flat and snugly on the pelvis ⇒ ...
Page 29 Fig. 15 Removing latch an accident. plate from buckle ● For pregnant women, the lap part of the seat belt must lie as low as ⇒ f ig. – Press the red button on the belt buckle 15. The latch plate possible over the pelvis, never across the stomach, and always lie flat so is released and springs out ⇒ ...
Page 30: Belt Tensioners
WARNING Note ● If the seat belt tensioners are triggered, a fine dust is produced. This is ● An incorrectly worn seat belt increases the risk of severe injuries. normal and it is not an indication of fire in the vehicle.
Page 31 Seat belts So that the effectiveness of the seat belt tensioner is not reduced and that removed parts do not cause any injuries or environmental pollution, regula- tions, which are known to the specialised workshops, must be observed. WARNING ● Improper use or repairs not carried out by qualified mechanics in- crease the risk of severe or fatal injuries.
Page 32: Airbag System
● If you are not wearing a seat belt, if you lean forward or to the side The airbag is deployed at high speed in fractions of a second. If you have an...
Page 33  WARNING ● If a child seat is secured to the front passenger seat, the risk to the Warning lamp for airbag and seat belt tensioner  child of sustaining critical or fatal injuries in the event of an accident in- creases.
Page 34 Airbag system Monitoring of airbag and belt tensioner system bag system may be damaged. In the event of an accident this could cause the airbag to inflate incorrectly or not inflate at all. Both the airbag and belt tensioner systems operation is constantly moni- tored electronically.
Page 35 Airbag system For the sake of the environment The airbags, which are a special type of waste, must be disposed of through an authorised service, because they contain pyrotechnic elements.  Safety First Operating Instructions Practical Tips Technical Specifications...
Page 36: Front Airbags
The airbag system is not a substitute for seat belts, but it is an integral part of the vehicle's overall passive safety system. Please bear in mind that the airbag system can only work effectively when the occupants are wearing their seat belts correctly and have adjusted the head restraints properly.
Page 37 ● there is a rear-end collision ● the vehicle turns over WARNING ● The seat belts and airbags can only provide maximum protection if the occupants are seated correctly ⇒ p age 10, Proper sitting position for occupants. ● If a fault has occurred in the airbag system, have the system checked immediately by a specialised workshop.
Page 38 Airbag system develop when the airbag deploys. This is normal and it is not an indication of fire in the vehicle.  Airbag covers when the frontal airbags are triggered Fig. 19 Airbag covers reacting when the front airbags are triggered The airbag covers fold out of the steering wheel or dash panel when the ⇒ ...
Page 39 ● If you are not wearing a seat belt, if you lean forward or to the side while travelling or assume an incorrect sitting position, there is a sub- stantially increased risk of injury.
Page 40: Side Airbags
Airbag system Side airbags The airbag system is not a substitute for seat belts, but it is an integral part of the vehicle's overall passive safety system. Please bear in mind that the airbag system can only work effectively when the occupants are wearing their seat belts.
Page 41  WARNING ● If you do not wear a seat belt, if you lean forward, or are not seated correctly while the vehicle is in motion, you are at a greater risk of injury Operation of side airbags if the side airbag system is triggered in an accident.
Page 42 ● Any damage to the original seat upholstery or around the seams of the side airbag units must be repaired immediately by a specialised workshop.
Page 43: Deactivating Airbags
Airbag system Deactivating airbags* Front passenger airbag deactivation If you fit a rear-facing child seat to the front passenger seat, the front passenger airbag must be de-activated. Fig. 22 Warning lamp for deactivated passenger airbag in centre console When the passenger airbag is deactivated, this means that only the passenger front airbag is deactivated.
Page 44 ● As soon as the child seat is no longer needed on the front passenger seat, enable the front passenger airbag again.
Page 45: Child Safety
Depending on their age, height and weight, children trav- As the driver, you are responsible for any children you transport in elling on the rear seat must use a child seat or a seat belt. For safety rea- your vehicle.
Page 46 However, if it is nec- ● Do not allow the seat belt to become twisted or jammed, or to rub on essary, in exceptional cases, to transport a child in the front passenger any sharp edges.
Page 47: Child Seats
(the letter E in a circle with the test num- Group 0+: For babies from about 18 months old and 13 kg in weight, the ber below it).
Page 48 Children over 7 years of age weighing between 22 and 36 kg but less than Read and always observe information and warnings concerning the use 1.5 metres tall are best protected by seat cushions with head restraints to- of child seats ⇒ ...
Page 49 ● The shoulder part of the seat belt must lie approximately on the cen- tre of the shoulder, never across the neck or the arm. The seat belt must lie close to the upper part of the body. The lap belt part must lie across the pelvis, not across the stomach, and always fit closely.
Page 50: Securing Child Seats
You can secure a child seat to the rear seat or front passenger seat in the senger airbag ⇒ p age 41, Deactivating airbags* must always be disabled following ways: and the seat adjusted to its highest position, where possible.
Page 51 – Pull on both sides of the child seat to ensure that it is secure. Two ISOFIX retaining rings are fitted on each rear seat. In some vehicles, the rings are secured to the seat frame and, in others, they are secured to the rear floor.
Page 52 (lift the head restraint where necessary). An undue installation of the safety seat will increase the risk of injury in the event of a crash. – Slide the belt so that the Top Tether belt of the child restraint seat is correctly secured to the anchor on the back of the rear ●...
Page 53 Child safety Safety First Operating Instructions Practical Tips Technical Specifications...
Page 54 Cockpit Fig. 29 Dash panel...
Page 55: Operating Instructions
Cockpit Operating Instructions Cockpit Overview Radio Glove compartment/Storage compartment ....Passenger airbag* ........Overview of the dash panel Switches for: This overview will help you to familiarise yourself with the...
Page 56: Cockpit
Cockpit Steering column control lever* ......Bonnet release lever ........Steering column controls for audio and telephone* .
Page 57: Instruments
Cockpit Instruments Instrument overview The instruments display the vehicle operating status. Fig. 30 Detailed view of the dash panel: instrument panel The layout of the instruments depends upon the model and the engine. Rev counter* ⇒ p age 56 Digital display ⇒ p age 57 Speedometer ⇒ ...
Page 58: Lpg System
Cockpit Rev counter LPG system* The rev counter displays the engine speed in revolutions per LPG gauge minute. ⇒ f ig. 30 The start of the red zone indicates the maximum engine speed operating at service temperature. However, it is advisable to change up a in- to a higher gear, move the selector lever to D or lift your foot off the acceler- ator before the needle reaches the red zone.
Page 59: Digital Instrument Panel Display
Cockpit Digital instrument panel display WARNING LPG is a highly explosive and inflammable substance. It may cause se- Fuel gauge  and reserve indicator vere burns and other injury. ● Due care must be taken to avoid any risk of fire or explosion. ●...
Page 60: Digital Clock
Cockpit Digital clock* Recommended gear display* This display helps to save fuel. ⇒ f ig. – To set the hour, press button 30. The “hour” option flashes on the digital display and is set using button “set” ⇒ f ig. –...
Page 61 Cockpit Multifunction display (MFI)* The trip memory 1 collects the travel and consumption rates from the mo- ment the ignition is switched on until it is switched off. If the journey is con- The multifunction display (MFI) shows you information on tinued within two hours of switching off the ignition, the new values will be added to the existing trip recorder memory.
Page 62 Cockpit Memory displays The maximum display value in both memories is 1999 km. The memory will automatically be deleted once this value has been reached. ● Driving speed ● Journey duration - Fuel range  Km ● Average speed The fuel range is calculated using the figures for tank content and current fuel consumption.
Page 63 Cockpit This may be deactivated by pressing the button. The speed may be The position of the automatic selector lever is shown on the display RESET ⇒ p age 152. altered using the rocker switch in steps of 5 km/h within 5 seconds of ...
Page 64 The service pre-warning will ap- If the service was not performed by a SEAT dealer, the display must be reset pear at 20 days or less prior to the corresponding service. The distance trav- as follows: elled is rounded off to the nearest 100 km and the time to full days.
Page 65: Warning Lamps
Cockpit Warning lamps Overview of the warning lamps The warning lamps indicate a number of different functions and possible faults. Fig. 38 Instrument panel warning and indicator lamps. Some of the items of equipment listed here are fitted only on certain model versions or are optional extras. ...
Page 66 Rear fog light switched on  ⇒ p age 73 Electro-hydraulic steering  ⇒ p age 20 Seat belt warning lamp*  Fault in the emission control system ⇒ p age 73  ⇒ p age 69 Anti-lock brake system (ABS) * ...
Page 67 Cockpit Overview of indicator and warning lamps (vehicles with Meaning of warning and indicator Further infor- Item Symbol lamps mation LPG)   ⇒ p age 74 Turn signals in operation The warning lamps indicate a number of different functions and possible faults.
Page 68: Warning Symbols
Cockpit If several priority 1 faults are detected at the same time, the symbols will be WARNING displayed one after the other for about 2 seconds at a time and will contin- ue until the fault is corrected. ● Failure to observe warning lamps and warning messages can result in serious personal injury or damage to your vehicle.
Page 69 Cockpit Information messages displayed on the screen* STOP TRANS- Warning: Stop the engine. Gearbox overheated. MISSION TOO HOT Message Description Warning: To start the engine, press the brake pedal. Only in The service interval has ended. Take the vehicle to an au- BRAKE SERVICE vehicles with automatic gearbox.
Page 70: Engine Oil Pressure
Cockpit Glow plug system / Engine fault*  WARNING The warning lamp lights up to show that the glow plugs are ● Always drive according to the road weather conditions, the terrain preheating. It flashes if there is an engine fault. and traffic.
Page 71: Washer Fluid
Cockpit Bulb defect*  There is a fault in the ABS if: ● The warning lamp  does not light up when the ignition is switched on. The indicator lights up when a bulb is not functioning. ● The warning lamp does not go out again after a few seconds ●...
Page 72 Cockpit Differential lock fault (EDL)* Electronic Stability Programme (ESP)*  /  EDL operates along with the ABS in vehicles equipped with There are two warning lamps for the electronic stability pro- an Electronic Stability Programme (ESP)* gramme. The  lamp provides information concerning the function and the ...
Page 73: Brake System
Cockpit Brake system*  Tyre pressure*  This warning lamp lights up if the brake fluid level is too low or if there is a fault in the system. This warning lamp  lights up if ● the brake fluid level is too low ⇒ p age 211. ●...
Page 74 Cockpit Speed selector lever lock*  Tyre pressure adjustment Following the modification to tyre pressure or changing one or more wheels, ⇒ f ig. 40 the button must be kept pressed while the ignition is on until an The brake pedal must be depressed when this warning lamp lights up. This acoustic signal is heard.
Page 75: Emission Control System
Cockpit Main beam headlights  Emission control system*  This warning lamp lights up when the main beams are on. This warning lamp monitors the exhaust system. The warning lamp  is switched on once main beams are on or once the Warning lamp ...
Page 76 Cockpit If the warning lamp lights up again after driving on for a short distance, You should avoid using electrical equipment that is not absolutely necessa- stop the vehicle and switch the engine off. Contact an Authorised Service ry because this will drain the battery. Centre or a specialised workshop.
Page 77 Cockpit The engine can, however, be started if the appropriate coded SEAT genuine key is used. Note The vehicle cannot operate properly if you do not have a genuine SEAT key.  Safety First Operating Instructions Practical Tips Technical Specifications...
Page 78: General Information
Steering column controls* Steering column controls* General information The column incorporates multifunctional modules from which to control au- dio and telephone functions on the vehicle. There are two versions of the multifunction module: ● Audio version, to control the available audio functions from the steering wheel.
Page 79: Audio Control
Steering column controls* Audio Control Fig. 41 Audio controls Short press Button Radio CD Audio CD MP3/USB/iPod AUX-IN Volume up Volume down Cycle through source FM - AM - CD - FM... Station search. Higher frequency No function Next track .
Page 80: Audio + Telephone Control
Steering column controls* Audio + Telephone Control Fig. 42 Audio + Tele- phone Control Short press Long press Button CD MP3/USB/ CD MP3/USB/ Radio AUX-IN Radio AUX-IN iPod iPod Volume up Continue volume up Volume down Continue volume down Enable voice recognition. Press to speak No function specified Station search.
Page 81: Central Locking
Unlocking and locking Unlocking and locking Central locking WARNING ● Locking from the outside carelessly or without good visibility may Description lead to bruising, particularly in the case of children. ● When locking a vehicle, never leave children unaccompanied inside, The central locking system enables you to lock and unlock as from the outside it will be difficult to provide assistance if required.
Page 82 Unlocking and locking Once this system is activated, opening doors from the outside and the in- WARNING side is not possible. The tailgate can not be opened. The central locking button does not work. No one should remain inside the vehicle if the “Safe” mechanism is acti- vated because opening the doors will not be possible in case of emergen- When the ignition is switched off, the instrument panel indicates that the cy neither from the inside nor the outside.
Page 83 Unlocking and locking Activating the selective unlocking system* Unlocking With the door open, insert a key into the start cylinder and start the ignition. On withdrawing the ignition key, the vehicle will returns to its status prior to Insert the other key into the driver door lock and turn in the opening direc- self-locking.
Page 84 Unlocking and locking Emergency unlocking system The central lock button is still operative when the ignition is switched off. Except when the Safe security system is activated. If the airbags are triggered during an accident, the vehicle is unlocked, ex- Please note the following if you lock your vehicle with the central lock but- cept for the luggage compartment.
Page 85 Unlocking and locking Childproof lock Deactivating the childproof lock – Unlock the vehicle and open the door whose childproof lock you The childproof lock prevents the rear doors from being want to deactivate. opened from the inside. This system prevents minors from opening a door accidentally while the vehicle is running.
Page 86: Keys
Unlocking and locking Keys Duplicate keys If you need a replacement key, go to an Authorised Service Centre with your vehicle identification number. Set of keys WARNING The set of keys includes a remote control, a key without a re- mote control and a plastic key tab* ●...
Page 87: Radio Frequency Remote Control
Unlocking and locking Radio frequency remote control* Locking and unlocking the vehicle The remote control key is used to lock and unlock the vehicle from a distance. Fig. 47 Range of the re- mote control ⇒ f ig. 46 Using the button (arrow) on the control, the key blade is released.
Page 88 Unlocking and locking For the sake of the environment WARNING Used batteries must be disposed of at an appropriate waste facility or ● An improper use of the key can cause serious injuries. through an authorised service, given that their components can affect the ●...
Page 89: Anti-Theft Alarm System
Unlocking and locking Anti-theft alarm system* ● Opening of vehicle with mechanical key without switching ignition on within the next 15 seconds ● Opening a door Description of anti-theft alarm system* ● Opening the bonnet ● Opening the tailgate The anti-theft alarm triggers if unauthorised movements are ●...
Page 90 Unlocking and locking The interior monitoring and the anti-towing alarm are automatically switch- Note ed on again next time the vehicle is locked. ● After 28 days, the indicator light will be switched off to prevent the bat- The interior monitoring and anti-towing alarm (tilt sensor) are automatically tery from exhausting if the vehicle has been left parked for a long period of switched on when the anti-theft alarm is switched on.
Page 91 Unlocking and locking Note ● If the vehicle is relocked and the alarm is activated without the volumet- ric sensor function, relocking will activate the alarm with all its functions, except the volumetric sensor. This function is reactivated when the alarm is switched on again, unless it is deliberately switched off.
Page 92: Tailgate
Unlocking and locking Tailgate Unlocking and locking The operation of the tailgate opening system is electric. It is activated by using the handle on the tailgate Fig. 49 Detail of the in- side of the tailgate: hand grip Opening the tailgate ⇒ ...
Page 93 Unlocking and locking Emergency opening WARNING This allows the vehicle to be opened if the central locking ● Always close the tailgate properly. Risk of accident or injury. does not operate (for example, if the battery is flat) ● The tailgate must not be opened when the reverse or rear fog lights are lit.
Page 94: Windows
Unlocking and locking Windows Buttons on the driver door Button for window in front left door Button for window in front right door Opening or closing the windows electrically* Safety switch for deactivating the electric window buttons in the rear doors The front and rear electric windows can be operated by us- Button for window in rear left door...
Page 95 Unlocking and locking Restoring one-touch opening and closing WARNING (Continued) – The automatic open and close function will not work if the bat- ● The electric windows will work until the ignition has been switched tery has been temporarily disconnected. The function can be re- off and one of the front doors has been opened.
Page 96 Unlocking and locking Convenience opening and closing* ● If the window is still obstructed, the window will stop at this point. ● If there is no obvious reason why the window cannot be closed, try to close it again by pulling the tab within ten seconds. The window closes with Using the door lock* maximum force.
Page 97: Panorama Tilting Sunroof* . . . . . . . . . . . . . . . . . . 95 Practical Tips
Unlocking and locking Panorama tilting sunroof* Automatic opening of the panorama/ tilting sunroof – Press button once only. The sunroof starts opening automat- ically until it is completely open. Opening and closing the panorama/tilting sunroof Restoring one-touch opening and closing The panorama/tilting sunroof is opened and closed by using –...
Page 98 Unlocking and locking Operation in case of breakdown WARNING (Continued) tilting sunroof) with a risk of accident. The doors can be locked using the In case of a breakdown, the sunroof may be closed manual- remote control key. This could make the aid difficult in an emergency sit- uation.
Page 99: Lights And Visibility
Lights and visibility Lights and visibility Lights Switching on the front fog lights* – Turn the switch from position  or  to the first stop and pull it. The symbol  in the light switch lights up. Switching lights on and off  Switching on the rear fog light (vehicles with front fog lights) –...
Page 100: Automatic Lighting
Lights and visibility ● The rear fog light is so bright that it can dazzle drivers behind you. You WARNING should use the rear fog light only when visibility is very poor. ● The use of the lighting described here is subject to the relevant statutory ●...
Page 101: Daytime Running Lights
Lights and visibility Instrument and switch lighting / Headlight range control Dynamic headlight range control Vehicles with gas discharge bulbs (xenon bulbs) are equipped with dynamic headlight range control. When you switch on the lights, their range regu- lates itself according to the vehicle load. Vehicles with gas discharge bulbs do not have headlight range control.
Page 102 Lights and visibility Adaptive headlights* (for driving round bends) Fog lights with cornering function* When driving around bends, the headlights will light the This is an additional light source to dipped beam headlights most important areas of the road. to light up the road as a bend is taken. The cornering light operates with the lights switched on and when driving at less than 40 Km/h.
Page 103 Lights and visibility Home lighting comes on. If the driver door is already open when the lights Note are flashed briefly, the Coming Home lighting comes on immediately. ● To activate the coming/leaving home function, the rotary light switch When the last door of the vehicle or the tailgate is closed, the Coming Home must be in position ...
Page 104: Hazard Warning Lights
Lights and visibility 2. Press the button to switch on the hazard warning lights ⇒ . For the sake of the environment 3. Switch the engine off. The heated rear window should be disconnected as soon as the glass is demisted.
Page 105 Lights and visibility Signalling a lane change Note – Push the lever up or down to the point where you incur ● The battery will run down if the hazard warning lights are left on for a resistance and then release it. The turn signal will flash several long time, even if the ignition is switched off.
Page 106: Interior Lights
Lights and visibility Interior lights Note ● The turn signals only work when the ignition is switched on. The corre- sponding warning lamp  or  flashes in the instrument panel. The warn- Front interior light ing lamp  flashes when the turn signals are operated, provided a trailer is correctly attached and connected to the vehicle.
Page 107: Visibility
Lights and visibility Luggage compartment light* Note If not all the vehicle doors are closed, the interior lights will be switched off The light is activated when the tailgate is open, even when the ignition and after approx. 10 minutes, providing the key has been removed and the cour- lights are turned off.
Page 108: Windscreen Wipers
Lights and visibility Windscreen wipers The sun visors for the driver and the front passenger can be pulled out of their central supports and turned towards the doors in the direction of the ⇒ f ig. arrow 63. Never pull them downwards. Front windscreen wipers ...
Page 109 Lights and visibility short intervals. Four wiper interval stages can be set using CAUTION switch In icy conditions, always check that the wiper blades are not frozen to the glass before using the wipers for the first time. If you switch on the wipers Slow wipe when the wiper blades are frozen to the windscreen, you could damage –...
Page 110 Lights and visibility Rain sensor* Rear window wiper  The rain sensor controls the frequency of the windscreen The windscreen wiper lever operates the windscreen wiper wiper intervals, depending on the amount of rain. and the wash and wipe system for the rear window. Fig.
Page 111: Rear View Mirrors
Lights and visibility – Release the lever. The washer system stops and the wipers con- Note tinue until the end of the cycle. ● To ensure that the headlight washers work properly in winter, keep the – Move the lever towards the steering wheel to switch off. nozzle holders in the bumper free of snow and remove any ice with a de-icer spray.
Page 112 Lights and visibility Automatic anti-dazzle interior mirror* Note The automatic anti-dazzle function can be switched on and ● The automatic anti-dazzle function will only work properly if the sun blind* for the rear window is retracted and there are no other objects pre- off as desired.
Page 113 Lights and visibility Electric exterior mirrors* – The mirrors demist for some minutes to prevent draining the battery. The exterior mirrors can be adjusted using the rotary knob – If necessary, press the button again to repeat the function. in the driver door. –...
Page 114 Lights and visibility Note ● If the electrical adjustment ever fails to operate, the mirrors can be ad- justed by hand by lightly pressing the edge of the mirror glass. ● In vehicles with electric exterior mirrors, the following points should be observed: if, due to an external force (e.g.
Page 115: The Importance Of Correct Seat Adjustment
● Always keep your feet on the footwell when the vehicle is moving; Proper seat adjustment optimises the level of protection of- never rest them on the dash panel, out of the window or on the seat. This fered by seat belts and airbags.
Page 116: Head Restraints
Fig. 70 Side view: head restraints and seat belts correctly adjusted – Adjust the head restraint so that the top is at the same level as the top of your head or as close as possible to the same level as ⇒ ...
Page 117 – Make sure that it engages securely into position. Note Adjusting height (rear seats) ● To fit and remove the rear head restraints, gently tilt the seat backrest – Press the button on the side and pull upwards to the desired forwards.
Page 118: Front Seats
Seats and storage compartments Front seats WARNING ● Never adjust the driver or front passenger seat while the vehicle is in Adjustment of the front seats motion. While adjusting your seat, you will assume an incorrect sitting position. Risk of fatal accidents. Adjust the driver or front passenger seat only when the vehicle is stationary.
Page 119 Heated seats*  CAUTION The front seat cushions and backrests can be heated electri- To avoid damaging the heating elements, please do not kneel on the seat or apply sharp pressure at a single point to the seat cushion and backrest. cally.
Page 120: Rear Seats
– Pull the release button in the direction of the arrow and fold the backrest forwards – Insert the head restraints in the spaces on the rear of the seat cushion which are visible when the seat cushion is lowered. Folding seat forward –...
Page 121 ● Do no trap or damage seat belts when raising the backrest. ● After raising the backrest, check it has engaged properly in position. Do this by pulling on the central seat belt or directly on the backrest and check that the position lever is in the neutral position.
Page 122: Storage Compartment
Seats and storage compartments Storage compartment This compartment can hold documents in A4 format, a water bottle of 1.5 L,... Storage compartment on the front passenger side WARNING Always keep the storage compartment cover closed while the vehicle is in motion in order to reduce the risk of injury caused by a sudden braking or by an accident.
Page 123 Fig. 79 Mounting brack- et for navigator on dash panel. Fig. 81 Storage com- partment under the front seat To open – The compartment is opened by pulling on the lever and assist- ing it with your hand. To close –...
Page 124 Seats and storage compartments Seat storage pocket* Front drink holder* Fig. 82 Seat storage Fig. 83 Front cup hold- pocket ers in the centre console There is a storage pocket on the rear of the front seats. There are two cup holders in the centre console in front of the gear lever ...
Page 125: Ashtrays, Cigarette Lighter And Power Socket
Seats and storage compartments Rear drink holder* Ashtrays, cigarette lighter and power socket Ashtray* Fig. 84 Cup holder in the centre console On the rear part of the centre console, behind the hand brake, there is a cup ⇒ f ig. holder installed* Fig.
Page 126: Cigarette Lighter
Seats and storage compartments Cigarette lighter* Power socket Fig. 87 Front power Fig. 86 Lighter socket ⇒ f ig. 86 to activate it ⇒ . – Press on the cigarette lighter The 12 Volt cigarette lighter power socket can also be used for other electri- cal components with a power rating of up to 120 Watt.
Page 127 Seats and storage compartments Power socket in the luggage compartment* Auxiliary audio input connection (AUX)* Electrical equipment can be connected to the 12 volt socket. Fig. 89 AUX connection on the central console (depending on the equip- Fig. 88 Detailed view of ment) the side trim in the lug- gage compartment: 12...
Page 128: First-Aid Kit, Warning Triangle, Fire Extinguisher
Seats and storage compartments AUX/USB input connection* First-aid kit, warning triangle, fire extinguisher Warning triangle* Fig. 90 AUX/USB* input connection (depending on the equipment) For information concerning the use of this equipment, please see the Radio Fig. 91 Housing for the emergency warning trian- handbook.
Page 129: Luggage Compartment
Seats and storage compartments First-aid kit and fire extinguisher* ● Ensure that the fire extinguisher is fully functional. The fire extinguisher should, therefore, be checked regularly. The sticker on the fire extinguisher will inform you of the next date for checking. ●...
Page 130 Seats and storage compartments ⇒ f ig. Fastening rings* – Position heavy items as far forward as possible – Secure the load with a luggage net* or with non-elastic straps There are four fastening rings in the luggage compartment, secured to the fastening rings ⇒ p age 128. which can be used to secure loads.
Page 131 Seats and storage compartments Luggage net* Rear shelf The luggage net can be used to secure and retain light items in the luggage compartment. Fig. 96 Rear shelf Removing the shelf Fig. 95 Stretched lug- gage net ⇒ f ig. 96 –...
Page 132 Seats and storage compartments Note ● Ensure that, when placing items of clothing on the luggage compart- ment cover, rear visibility is not reduced.  Rear shelf with storage compartment* Fig. 98 Accessing stor- age compartment To remove the storage compartment –...
Page 133: Roof Rack
Please observe the following points if you intend to carry loads on the roof: ● For safety reasons, only luggage racks and accessories approved by SEAT should be used. ● It is essential that you follow the assembly instructions included with...
Page 134: Air Conditioning
Air conditioning Air conditioning Heating which is needed to defrost the windows quickly, is only available when the engine has reached its operating temperature. Blower Controls The air flow can be set at four speeds with switch . The blower should al- ways be set at the lowest speed when driving slowly.
Page 135 Air conditioning Ventilating the passenger compartment WARNING ⇒ f ig. 100 – Turn the temperature selector anti-clockwise. ● For your safety, the windows should never be fogged up or covered – Turn blower switch to any of the head settings 1 -4. with snow or ice.
Page 136 Air conditioning – Turn blower switch to any of the head settings 2 -3. Heating Maximum heat output, which is needed to defrost the windows quickly, is – Turn air distribution control to . only available when the engine has reached its operating temperature. –...
Page 137: Air Conditioning
Air conditioning Air distribution The air conditioning system only works when the engine is running and the fan is switched on. Switch on symbol Main air output through outlets: ⇒ f ig. 102 – Using the controls and with the switch ...
Page 138 Air conditioning – Turn the temperature selector to set the desired temperature WARNING inside the vehicle. For your safety, the windows should never be fogged up or covered with – Turn the blower switch to any of the settings 1-4. snow or ice.
Page 139: Air Recirculation
Air conditioning ● The engine is stationary. WARNING ● The fan blower is switched off. ● The outside temperature is below +3 ℃. In air recirculation mode, no cold air from the outside enters the vehicle interior. If the air conditioner is switched off, the windows can quickly ●...
Page 140: Climatronic
Air conditioning Climatronic Interior temperature indicator selected Air flow direction indicator Fan speed increase Controls Fan speed decrease Interior temperature increase Interior temperature decrease button – Automatic adjustment of temperature, ventilation and AUTO air distribution Button – Windscreen demisting function. The air drawn in is direc- ...
Page 141 Air conditioning Automatic mode Manual mode In automatic mode air temperature, air flow and distribution In manual mode the air temperature, flow, and the desired are automatically regulated so that a specified temperature air distribution can be adjusted. is attained as quickly as possible, and then maintained. Switching on manual mode Switching on automatic mode ⇒ ...
Page 142: General Notes
Air conditioning Air recirculation mode General notes Air recirculation mode prevents fumes or unpleasant smells Pollution filter from coming from the outside. The pollution filter (a combined particulate filter and active carbon filter) serves as a barrier against impurities in the outside air, including dust and –...
Page 143 Air conditioning ● The air conditioner operates most effectively with the windows and the sliding/tilting sunroof* closed. However, if the temperature inside the vehi- cle is excessive because of the sun, the air inside can be cooled faster by opening the windows for a short time. ●...
Page 144: Driving
The height and reach of the steering wheel can be freely ad- when the vehicle is stationary. justed to suit the driver. ● Adjust the driver seat or steering wheel so that there is a distance of ⇒ f ig. at least 25 cm between the steering wheel and your chest 105.
Page 145: Safety
Driving Safety WARNING ● The Electronic Stability Programme (ESP) cannot defy the laws of Electronic Stability Programme (ESP)* physics. This should be kept in mind, particularly on slippery and wet roads and when towing a trailer. ESP helps make driving safer in certain situations. ●...
Page 146: Electronic Immobiliser
The engine can only be started using a genuine SEAT key with its correct Every time the vehicle is started again, the ignition key must be turned to code.
Page 147: Starting And Stopping The Engine
Risk of fatal accidents. Carbon monoxide can cause loss of The engine can only be started using a genuine SEAT key consciousness. It can also cause death. with its correct code.
Page 148 Driving Starting diesel engines WARNING The engine can only be started using a genuine SEAT key ● Never start or run the engine in unventilated or closed rooms. The ex- with its correct code. haust fumes contain carbon monoxide, an odourless and colourless poi- sonous gas.
Page 149 For this reason, you should idle the engine for approx. 2 minutes before you Your SEAT vehicle has a bivalent engine able to run on either LPG or petrol. The LPG tank ⇒ p age 195, Refuelling with LPG is in the spare wheel well switch it off.
Page 150: Start-Stop Function
Driving ● There is enough LPG in the tank. WARNING ● The temperature of the vehicle coolant is above 30 °C. LPG is a highly explosive and inflammable substance. It may cause se- ● Engine speed while driving is above 1200 rpm. vere burns and other injury.
Page 151 ● Temperature setting is selected. ● The engine coolant temperature is insufficient. ● The driver seat belt must be buckled. ● The engine hood must be closed. ● The alternator is faulty, for example the V-belt has ruptured. ● If any of the conditions described in the previous section are not fulfil- ●...
Page 152 Driving Activating and deactivating the Start-Stop function Driver messages Fig. 109 The Start-Stop function button. Fig. 110 Display on the instrument panel during Start-Stop function operation. Every time the ignition is switched on, the Start-Stop function is au- When the engine is turned off by the Start-Stop function, this is displayed tomatically switched on.
Page 153: Manual Gearbox
Driving Manual gearbox The reverse lights light up when the reverse gear is selected and the igni- tion is on. Driving with a manual gearbox WARNING ● When the engine is running, the vehicle will start to move as soon as a gear is engaged and the clutch released.
Page 154: Automatic Gearbox
Driving Automatic gearbox* If you select the sport programme, S, you will drive in a sporty mode, i.e. a programme in which shifts into high gears are postponed in order to use the full power of the engine.  Gearbox programmes The automatic gearbox has got two gearbox programmes.
Page 155 Driving Selector lever lock functions The selector lever lock is released as follows: – Switch the ignition on. The selector lever lock in position P or N prevents gears from being engaged inadvertently, which would cause the vehicle – Hold the brake pedal pressed down and at the same time, hold to move.
Page 156 Driving Driving a car with an automatic gearbox Stopping briefly – If stopping for a short time, keep the vehicle stationary by The gearbox changes gear ratios automatically as the vehi- pressing the foot brake hard to prevent the car moving back- cle moves.
Page 157 Driving – With a selected gear, accelerate slowly and at the same time, WARNING (Continued) release the handbrake. ● Never accelerate when moving the selector gear or you may cause an accident. The steeper the slope, the lower the needed gear. This increases the brak- ●...
Page 158 Driving Changing gear in tiptronic mode* Changing gear in tiptronic mode – Press the selector lever from position D to the right into the tip- The tiptronic system allows the driver to select gears man- tronic selector gate. ually – Lightly press the selector forward + to change up into high gears.
Page 159 Driving Changing gears in the normal or sport programme using the steering wheel Selector lever positions paddle levers The selected gear is displayed on the side of the selector lever and on the ⇒ f ig. 117 If the paddle levers are used in the normal or sport programme, instrument panel screen.
Page 160 Driving ● The wiper starts if the windscreen washer is on. WARNING ● The parking distance warning system switches on.* If the vehicle moves with no control, an accident and serious injury may N - Neutral (idling) occur. If this position is selected, the gearbox is in neutral. Power is not transmit- ●...
Page 161: Handbrake
Driving WARNING (Continued) WARNING ● The brake servo does not work with the engine off. You need more You could lose control of the vehicle if you accelerate on slippery road force to stop the vehicle. surfaces. Risk of serious injury. ●...
Page 162 Driving Parking Always apply the handbrake when you leave your vehicle and when you park. The handbrake should always be firmly applied when the Applying the handbrake vehicle is parked. ⇒ f ig. – Pull the handbrake lever up firmly 119.
Page 163: Acoustic Parking Aid System
Driving WARNING WARNING ● Take measures to reduce the risk of injury when you leave your vehi- ● If you do not start the vehicle immediately after taking your foot off cle unattended. the brake pedal, the vehicle may start to roll back under certain condi- tions.
Page 164 Driving Activation If there is no ready signal or no acoustic warning signal, then the parking aid loudspeaker is faulty and may not warn of obstacles. The system is activated by engagement of the reverse gear. A brief acoustic signal confirms the activation and correct function of the system. To ensure that the system works properly, the sensors must be kept clean and free of ice and snow.
Page 165: Cruise Speed* (Cruise Control System)
Driving ● External ultra-sonic sources (pneumatic drills, construction machinery, Note other vehicles with PDC) may interfere with the operation of the system. The cruise control cannot maintain a constant speed when descending ● Periodic cleaning of the sensors, take care not to damage or scratch downhill.
Page 166 Driving Adjusting set speed* When the cruise control is on and a speed is programmed, the indicator  on the instrument panel is lit. The speed can be altered without touching the accelerator or If the cruise control system is switched off, the  symbol is switched off. the brake.
Page 167 Driving When you increase speed with the accelerator and then release the pedal, ● if the brake pedal is depressed, the system will automatically restore the set speed. This will not be the ● if the clutch pedal is depressed, case, however, if the vehicle speed is more than 10 km/h higher than the ●...
Page 168 Driving Vehicles with a manual gearbox The system is completely turned off by moving the control all the way to the right hand side (OFF engaged), or when the vehicle is stationary, igni- tion off. Vehicles with an automatic gearbox To completely disengage the system, the selector lever must be placed in one of the following positions: P, N, R or 1 or with the vehicle stopped and the ignition turned off.
Page 169: Intelligent Technology
Intelligent technology Practical Tips Intelligent technology Brakes Hydraulic Brake Assist (HBA)* The Hydraulic Brake Assist function (HBA) is only included in Brake servo vehicles with ESP. The brake servo increases the pressure you apply to the brake pedal. It In an emergency, most drivers brake in time, but not with maximum force. works only when the engine is running.
Page 170: Anti-Lock Brake System And Traction Control Abs
Intelligent technology If you brake hard on a slippery road surface, the best possible control is re- WARNING tained as the wheels do not lock. ● The risk of accident is higher if you drive too fast, if you do not keep However, ABS will not necessarily guarantee shorter braking distances in all your distance to the vehicle in front, and when the road surface is slip- conditions.
Page 171: Electronic Stability Programme (Esp)
Intelligent technology XDS* TCS helps the vehicle to start moving, accelerate and climb a gradient in slippery conditions where this may otherwise be difficult or even impossi- Driveshaft differential ble. The TCS is switched on automatically when the engine is started. If necessa- When taking a bend, the driveshaft differential mechanism allows the outer ry, it may be turned on or off by briefly pushing the ESP button on the centre wheel to turn at a higher speed than the inner wheel.
Page 172 Intelligent technology Anti-lock brake system (ABS) Electronic Stability Programme (ESP)* ESP reduces the danger of skidding by braking the wheels individually. The anti-lock brake system prevents the wheels locking during braking The system uses the steering wheel angle and road speed to calculate the ⇒ ...
Page 173 Intelligent technology WARNING ● When accelerating on a slippery surface, for example on ice and snow, press the accelerator carefully. Despite EDL, the driven wheels may start to spin. This could impair the vehicle's stability. ● Always adapt your driving style to suit road conditions and the traffic situation.
Page 174: Driving And The Environment
Driving and the environment Driving and the environment Running-in Running in tyres and brake pads New tyres should be run-in carefully for the first 500 km. Running in a new engine New brake pads should be run-in carefully for the first 200 The engine needs to be run in over the first 1500 km.
Page 175: Exhaust Gas Purification System
Driving and the environment checked by an Authorised Service Centre more frequently than recommen- WARNING (Continued) ded in the Service Plan. ● Non-standard or damaged front spoilers could restrict the airflow to If you drive with wet brakes, for example, after crossing areas of water, in the brakes and cause them to overheat.
Page 176 Driving and the environment Diesel engine particulate filter* WARNING The diesel engine particulate filter eliminates soot produced The catalytic converter reaches very high temperatures! There is a risk of by burning diesel. fire. ● Never park where the catalytic converter could come into contact with dry grass or flammable materials under the vehicle.
Page 177: Economical And Environmentally Friendly Driving
Driving and the environment Drive anticipating the traffic situation WARNING A vehicle uses most fuel when accelerating. When you anticipate the situa- tion, you have to brake less often and, thus, accelerate less. If it is possible, ● The diesel engine particulate filter may reach extremely high temper- let the vehicle roll with a gear engaged, for example, if you see a red light atures;...
Page 178: Environmental Friendliness
Avoid short journeys rear window heating or the seat heaters*. To reduce the consumption and emission of polluting gases, the engine and the exhaust filtration systems should reach the optimum service tempera- Note ture.
Page 179: Driving Abroad
VI. carry out limited repairs. Manufacturing methods SEAT importers and distributors will gladly provide information about the technical preparations that you vehicle requires and also about necessary ● Use of recycled material for manufacturing plastic parts maintenance and repair possibilities.
Page 180: Trailer Towing
If the trailer has a 7-pin plug you will need to use an adapter cable. This is Check whether you can see enough of the road behind the trailer with the available in any SEAT dealer. standard mirrors. If this is not the case, you should have additional mirrors fitted.
Page 181: Driving Tips
Driving and the environment Ball coupling of towing bracket* Always brake in due course. If the trailer has an overrun brake, apply the brakes gently at first and then, firmly. This will prevent the jerking that can be caused by the trailer wheels locking. Select a low gear in due course be- The ball coupling is provided with instructions on fitting and removing the fore going down a steep downhill.
Page 182: Vehicle Maintenance And Cleaning
Vehicle maintenance and cleaning Vehicle maintenance and cleaning General notes WARNING Regular washing and care help maintain the value of your ● Car care products can be toxic. Because of this, they must always be kept closed in their original container. Keep them out of the reach of chil- vehicle.
Page 183: Care Of The Vehicle Exterior
Vehicle maintenance and cleaning Care of the vehicle exterior Washing by hand Vehicle washing Automatic car washing tunnel – First soften the dirt and rinse it off with water. The vehicle paintwork is so durable that the vehicle can normally be washed –...
Page 184 Vehicle maintenance and cleaning Washing the vehicle with a high pressure cleaner WARNING Be particularly careful when using a high pressure cleaner! ● Wash your vehicle with the ignition switched off. ● Protect your hands and arms from cuts on sharp metal edges when –...
Page 185 Vehicle maintenance and cleaning Vehicle paint maintenance Caring for plastic parts Regular waxing protects the paintwork. Solvents damage plastic parts. You need to apply wax to your vehicle if water does not form small drops If normal washing fails to clean plastic parts, clean them with approved sol- vent-free plastic cleaning and care products.
Page 186 Vehicle maintenance and cleaning Rubber seals maintenance If possible, use a de-icing spray to remove ice. If you use an ice scraper, push it in one direction only without swinging it. If rubber seals are well looked after, they will not freeze so Use window cleaner or a silicone remover to clean rubber, oil, grease and quickly.
Page 187: Underbody Protection
Vehicle maintenance and cleaning Every three months CAUTION – Apply a hard wax compound to the wheels. To prevent scratching chrome surfaces: ● Never use an abrasive cleaning product on chrome. Alloy wheels require regular attention to preserve their appearance. If road ●...
Page 188: Vehicle Interior Maintenance
Vehicle maintenance and cleaning WARNING WARNING Do not apply underseal or anti-corrosion coatings to the exhaust pipes, ● When working in the engine compartment, always observe the safety warnings ⇒ p age 199. catalytic converter or the heat shields on the exhaust system. The heat of the exhaust system or the engine could cause them to ignite.
Page 189 Cloth seat covers and fabric trim cleaning er-care product, available in your Authorised Service Centre. Cloth seat covers and fabric trim on the doors, headlining etc. can be – Apply these products very sparingly. cleaned with a special interior cleaner or with dry foam and a soft brush.
Page 190 WARNING the leather. ● Do not use chemical cleaning agents on the seat belts, as this can im- Dust and grit in the pores and seams can scratch and damage the surface. If pair the strength of the webbing. Ensure that belts do not come into con- the vehicle is under solar radiation for long periods, the leather should be tact with corrosive fluids.
Page 191: Accessories, Parts Replacement And Modifications
(e.g. cruise control system or electronically-con- ® ised Technical Service using Genuine SEAT Spare Parts.  trolled suspension) must be approved by SEAT and bear the e mark (the Eu- ropean Union's authorisation symbol). Safety First Operating Instructions Practical Tips...
Page 192: Roof Aerial
You will require an external aerial for mobile phones and ● external aerial incorrectly installed, two-way radios. ● transmitting power output in excess of 10 watts.  SEAT has approved for your vehicle the use of mobile telephones and two- way radios providing under the following conditions:...
Page 193: Fitting A Towing Bracket
Accessories, parts replacement and modifications The distance between the centre of the ball coupling and the ground should Note never be lower than the indicated value, even with a fully loaded vehicle Please observe the operating instructions of your mobile telephone / two- and including the maximum drawbar load.
Page 194 In certain versions this may entail fitting a heat insulating plate, which is why it is recommended that you go to a SEAT Dealer. In the event that the plate is not installed correctly, SEAT is exempt from any liability.
Page 195: Checking And Refilling Levels
Checking and refilling levels Checking and refilling levels Refuelling – Turn the key in the lock, without releasing the cap, clockwise through 180°. The tank flap is released manually. The tank holds approxi- – Remove the key and close the flap until it clicks into place. The mately 45 litres.
Page 196 Checking and refilling levels take longer than normal (up to one minute) for the engine to start firing. WARNING This is due to the fact that the fuel system has to purge itself of air before starting. ● Fuel is highly flammable and can cause serious burns and other inju- ries.
Page 197: Lpg System
Checking and refilling levels LPG system* Refuelling with LPG The LPG filler neck is behind the fuel cap, next to the petrol filler neck. Fig. 129 LPG tank in spare wheel well Refuelling with LPG – Before refuelling, stop the engine and switch off the ignition. –...
Page 198 Checking and refilling levels ⇒ f ig. 129 Adapter for the liquid petroleum gas (LPG) filler neck The LPG tank in the spare wheel well has a capacity of 52.8 litres. If the outside temperatures are very low, it may not be possible to complete- An adapter is required due to the existence of a range of ly fill the LPG tank.
Page 199 Note A series of collision tests performed on this vehicle while running with LPG For any fault in the LPG system, please refer to the SEAT web page, which have confirmed its high level of safety. lists the workshops authorised to repair these faults.
Page 200: Petrol
Checking and refilling levels Petrol tives. These additives will help to prevent corrosion, keep the fuel system clean and prevent deposits from building up in the engine. If good quality petrol with additives is not available or engine problems oc- Petrol types cur, the required additives must be added during refuelling.
Page 201: Working In The Engine Compartment
All service fluids and consumables, e.g. coolant, engine oil, spark plugs  and batteries, are under constant development. SEAT provides a constant flow of information to the Authorised Service Centres concerning modifica- tions. For this reason, we recommend you to have service fluids and con- sumables replaced by an Authorised Service Centre.
Page 202 Checking and refilling levels WARNING (Continued) WARNING ● If any work has to be performed when the engine is started or with All work on the engine or in the engine compartment, e.g. checking and the engine running, there is an additional, potentially fatal, safety risk refilling fluids, involves the danger of injury and scalding as well as the from the rotating parts, such as the drive belts, alternator, radiator fan, risk of accident or fire.
Page 203 Checking and refilling levels Opening the bonnet – To release the bonnet, pull the lever under the dash panel ⇒ f ig. 131 in the direction indicated (arrow). The bonnet will be The bonnet is released from inside the vehicle. released by a spring action ⇒ ...
Page 204: Engine Oil
Checking and refilling levels Service intervals WARNING Service intervals can be flexible (LongLife service) or fixed (dependent on time/distance travelled). If the bonnet is not closed properly, it could open while you are driving and completely obscure your view of the road. Risk of accident. If the PR code that appears on the back of the Maintenance Programme ●...
Page 205 Checking and refilling levels Vehicles with diesel particulate filter* Engine oil additives The “Maintenance Programme” states whether your vehicle is fitted with a No type of additive should be mixed with the engine oil. The deterioration diesel particulate filter. caused by these additives is not covered by the warranty. Only VW 507 00 engine oil, with reduced ash formation, may be used in die- Note sel engines equipped with particulate filter.
Page 206 Checking and refilling levels Topping up engine oil  – Wait two minutes. – Pull out the dipstick. Wipe the dipstick with a clean cloth and Top up gradually with small quantities of oil. insert it again, pushing it in as far as it will go. ⇒ ...
Page 207 Checking and refilling levels Engine oil specification ⇒ p age 203. WARNING Only change the oil yourself if you have the specialist knowledge re- WARNING quired! Oil is highly inflammable! Ensure that no oil comes into contact with hot ● Before opening the bonnet, read and observe the warnings engine components when topping up.
Page 208: Coolant
Checking and refilling levels Coolant CAUTION ● Other additives may give considerably inferior corrosion protection. The resulting corrosion in the cooling system can lead to a loss of coolant, caus- Coolant specifications ing serious damage to the engine. Coolant is a mixture of water and at least 40% coolant addi- ●...
Page 209 Checking and refilling levels Opening the coolant expansion tank WARNING – Switch off the engine and allow it to cool. Any work carried out in the engine compartment or on the engine must – To prevent scalding, cover the cap on the expansion tank with a be carried out cautiously.
Page 210: Washer Fluid And Windscreen Wiper Blades
Checking and refilling levels Washer fluid and windscreen wiper blades WARNING Any work carried out in the engine compartment or on the engine must Topping up washer fluid  be carried out cautiously. ● When working in the engine compartment, always observe the safety The water for cleaning the windscreen should always be warnings ⇒ ...
Page 211 Checking and refilling levels Changing windscreen wiper blades To change the blades it is necessary to change the rest position of the wipers to the service position. If the windscreen wiper blades are in perfect condition, you Do not change the windscreen wipers when out of the service posi- will benefit from an improved visibility.
Page 212 Checking and refilling levels Changing the rear wiper blade WARNING A good rear wiper blade is essential for clear rear vision. Do not drive unless you have good visibility through all windows! Damaged wiper blades should be replaced immediately. ● Clean the windscreen wiper blades and all windows regularly. ●...
Page 213: Brake Fluid
Checking and refilling levels Removing the wiper blade Brake fluid ⇒ f ig. – Lift the wiper arm away from the glass 139. Checking the brake fluid level – Slide the blade adapter in the direction of the arrow and remove ⇒ ...
Page 214 It is important that you use only brake fluid compliant with US standard FMVSS 116 DOT 4. We recommend the use of Genuine SEAT brake fluid. WARNING Brake fluid is poisonous. Old brake fluid impairs the braking effect.
Page 215: Vehicle Battery
Checking and refilling levels Vehicle battery WARNING (Continued) ● Fires, sparks, open flames and smoking are prohibited. When han- dling cables and electrical equipment, avoid causing sparks and electro- Warnings on handling the battery static charge. Never short the battery terminals. High-energy sparks can cause injury.
Page 216 The position of the battery is shown in the corresponding engine compart- has special safety features. ment diagram ⇒ p age 256. Genuine SEAT batteries fulfil the maintenance, performance and safety The “magic eye” indicator, located on the top of the battery changes colour, specifications of your vehicle.
Page 217: Wheels
Checking and refilling levels – When removed, the wheels and/or tyres should be stored in a WARNING cool, dry and preferably dark location. ● We recommend you use only maintenance-free or cycle free leak-proof – Store tyres in a vertical position if they are not fitted on wheel batteries which comply with standards T 825 06 and VW 7 50 73.
Page 218 Checking and refilling levels Checking tyre pressure Tyre service life The correct tyre pressure can be seen on the sticker on the The service life of tyres is dependent on tyre pressure, driv- inside of the tank flap. ing style and fitting. 1.
Page 219 The tyres and wheel rims are an essential part of the vehicle's design. The Unbalanced wheels should be rebalanced, as they otherwise cause exces- tyres and rims approved by SEAT are specially matched to the characteris- sive wear on steering, suspension and tyres. A wheel must also be reba- tics of the vehicle and make a major contribution to good road holding and lanced when a new tyre is fitted.
Page 220 This can also apply to wheels of the same model. The use of essary special tools and spare parts as well as the proper facilities for dis- wheels or tyres which have not been approved by SEAT for use with your posing of the old tyres.
Page 221 Checking and refilling levels Wheel bolts Winter tyres Wheel bolts must be tightened to the correct torque. Winter tyres will improve the vehicles handling on snow and ice. The design of wheel bolts is matched to the rims. If different wheel rims are fitted, the correct wheel bolts with the right length and correctly shaped In winter conditions winter tyres will considerably improve the vehicle's han- bolt heads must be used.
Page 222 Checking and refilling levels If you have a flat tyre, please refer to the notes on the spare wheel CAUTION ⇒ p age 217, New tyres and wheels. Remove the snow chains to drive on roads without snow. Otherwise they will impair handling, damage the tyres and wear out very quickly.
Page 223: If And When
If and when If and when Vehicle tools, spare wheel WARNING (Continued) ● Never start the engine when the vehicle is on the jack. Risk of acci- dent. Vehicle Tools ● If work is to be carried out underneath the vehicle, this must be se- The vehicle onboard tools are located under the floor panel cured by suitable means.
Page 224: Wheel Change
If and when Wheel change If you have a puncture on one of the front wheels when using snow chains, fit the compact temporary spare in place of one of the rear wheels. You can then attach the snow chains to the wheel taken from the rear and use this wheel to replace the punctured front wheel.
Page 225 If and when – Place the wheel with the defective tyre in the luggage compart- CAUTION ment and secure it. If you have to change the wheel on a slope, it is essential to lock the parallel wheel on the same axle as that to be changed, with a wedge or similar in –...
Page 226 If and when Wheel covers* Loosening the wheel bolts The wheel covers must be removed for access to the wheel The wheel bolts must be loosened before raising the vehicle. bolts Fig. 145 Changing the wheel: loosen the wheel bolts Fig.
Page 227 If and when WARNING Loosen the wheel bolts only about one turn before raising the vehicle with the jack, otherwise there is a risk of accident. Note ● If the wheel bolt is very tight, you may be able to loosen it by pushing down the end of the spanner carefully with your foot.
Page 228 If and when An unstable surface under the jack may cause the vehicle to slip off the If tyres with a specific direction of rotation are fitted, note the direction of jack. Therefore, the jack must be fitted on solid ground offering good sup- rotation.
Page 229: Tyre Repair Kit (Tyre-Mobility-System)
For the sake of the environment If you have to dispose of a sealant can, go to a specialised waste service or Tyre repair kit (Tyre-Mobility-System)* to a SEAT Technical Service, where the product can be recycled in an appro- priate waste container. ...
Page 230 If and when Note CAUTION ● If sealant should leak out, leave it to dry. This way you can pull it off like Take special care if you have to repair a tyre on a slope. a piece of foil. ●...
Page 231: Fuses
If and when – Unplug the compressor from the socket. – Identify the fuse corresponding to the damaged electric con- sumer ⇒ p age 230. – Return all tools to their proper storing location. – Take the plastic clip from inside the fuse cover, fit it onto the blown fuse and pull the fuse out.
Page 232 ● If you replace a fuse with higher-rating fuse, you could cause damage to another location in the electrical system. Right-hand AFS headlights ● Always keep some spare fuses in the vehicle. These are available from Vacant SEAT dealers.  Number plate light Clean pump Electronic control unit...
Page 233 If and when Fuses below steering wheel in relay holder Number Consumer Amps Main beam headlight, right 10, 15 PTC fuses Main beam headlight, left 10, 15 Number Consumer Amps Engine heater Supplementary electrical heating using air Vacant Supplementary electrical heating using air 12 Volt Input/Cigarette lighter Supplementary electrical heating using air Heated seats control unit / Cup Holder...
Page 234: Bulb Change
If and when Fuses in engine compartment above battery Bulb change General notes Before changing any bulb, first turn off the failed component. Do not touch the bulb glass. Fingerprints vaporise in the heat, causing a re- duction in the bulb life and condensation on the mirror surface, thus reduc- ing efficiency.
Page 235 If and when Xenon / adaptive headlights* For the sake of the environment Dipped and full beam - D1S Please ask your specialist retailer how to dispose of used bulbs in the prop- Position - LED er manner. DRL (day light) - LED Turn signals - PY 21W...
Page 236: Single Headlight Bulb Change
If and when Single headlight bulb change Turn signal bulb Single headlight bulb Fig. 152 Single turn sig- nal lamp – Raise the bonnet. Fig. 151 Single head- light ⇒ f ig. 152 – Rotate the bulb holder to the left and pull. Side lights - Dipped beam/main beam.
Page 237 If and when ⇒ f ig. 154 Dipped/main beam headlights – Remove the connector from the bulb. ⇒ f ig. 154 – Unclip the retainer spring pressing inwards to the right. – Extract the bulb and fit the replacement so that the rim of the attachment plate is on the reflector cut-out.
Page 238: Double Headlight Bulb Change
If and when ⇒ f ig. 153 – Move the loop in the direction of the arrow and Dipped beam headlights remove the cover. Turn signal lights  ⇒ f ig. 155 – Remove the bulb holder outwards. – Replace the bulb by pulling it out and inserting the replace- Side light ment.
Page 239 If and when – Raise the bonnet. – Move the loop in the direction of the arrow and remove the ⇒ f ig. cover 157. ⇒ f ig. 158 – Remove connector by pulling outward. – Remove the bulb by pulling it out and fitting the new one. –...
Page 240 If and when ⇒ f ig. 162 Dipped beam headlights – Remove the connector from the bulb. ⇒ f ig. 162 – Unclip the retainer spring pressing inwards to the right. – Extract the bulb and fit the replacement so that the rim of the attachment plate is on the reflector cut-out.
Page 241 If and when ⇒ f ig. 163 – Rotate the bulb holder to the left and pull. – Remove the bulb by pressing on the bulb holder and rotating at the same time to the left. – Installation is done in the reverse order. ...
Page 242: Changing The Bulbs Of Afs Headlights
If and when Changing the bulbs of AFS headlights Turn signal light bulb AFS headlight bulbs Fig. 165 Turn signal – Raise the bonnet. Fig. 164 AFS headlight bulbs ⇒ f ig. 165 – Rotate the bulb holder to the left and pull. Turn signal lights –...
Page 243: Changing The Fog Light Bulbs
If and when ⇒ f ig. 166 Changing the fog light bulbs – Remove the bolt from the fog light grill with a screwdriver. Fog lights bulb – Subsequently, unclip the clips situated on the contour of the grill by making a small movement of the lever. ⇒ ...
Page 244: Changing The Rear Lights (On The Wing)
If and when – Installation is done in the reverse order. – Open the tailgate. – Check that the bulb functions. – Look for a lid with a grill behind the side lights.  – Remove the lid with a flat screwdriver, placing it in notch ⇒ ...
Page 245: Changing The Rear Lights (On The Tailgate)
If and when Changing the rear lights (on the tailgate) Changing bulbs Overview of tail lights Lights on the tailgate ● Reverse lights ● Side lights ● Fog lights  Accessing the tailgate lights Fig. 172 Removing the bulb holder –...
Page 246: Side Turn Signal Bulbs
If and when Side turn signal bulbs Number plate light Fig. 173 Side turn sig- Fig. 174 Remove the nals number plate light. – Press the turn signal to the left or to the right to remove the – Insert the flat part of a screwdriver into the special slot and re- bulb.
Page 247: Interior Light And Front Reading Lights
If and when Interior light and front reading lights – First fit the glass with the fastening tabs over the frame of the switch. Next press the front part until the two long tabs click on the support.  Additional brake lights* Given the difficulty involved in the replacement of this light it should be done by the Technical Service.
Page 248: Luggage Compartment Light
If and when Luggage compartment light – Press the bulb sideways and remove it from its housing ⇒ f ig. 177.  Jump-starting Jump leads The jump lead must have a sufficient wire cross section. If the engine fails to start because of a discharged battery, the battery can be connected to the battery of another vehicle to start the engine.
Page 249 If and when How to jump start: description 2. Connect one end of the red jump lead to the positive terminal ⇒ f ig. 178 ⇒ f ig. 179 of the vehicle with the flat bat- tery 3. Connect the other end of the red jump lead to the positive ter- minal in the vehicle providing assistance 4.
Page 250 If and when 11. Turn on the heater blower and heated rear window in the vehi- WARNING (Continued) cle with the flat battery. This helps minimise voltage peaks ● The non-insulated parts of the battery clamps must not be allowed to which are generated when the leads are disconnected.
Page 251: Towing And Tow-Starting
If and when Towing and tow-starting Comments Please observe the following points if you use a tow-rope: Tow-starting* Notes for the driver of the towing vehicle The use of jump leads is preferable to tow-starting. – Drive slowly at first until the tow-rope is taut. Then accelerate gradually.
Page 252 If and when Do not pull too hard with the towing vehicle and take care to avoid jerking ● The steering wheel is locked when the vehicle has no electrical power. the tow-rope. When towing on an unpaved road, there is always a risk of The vehicle must then be towed with the front wheels raised.
Page 253 If and when Rear towing eye Fig. 181 Rear towing ring There is a towing eye at the rear on the right below the rear bumper.  Safety First Operating Instructions Practical Tips Technical Specifications...
Page 254: Technical Specifications
Description of specifications Technical Specifications Description of specifications Important information Abbreviation Meaning Cetane number, indication of the diesel combustion pow- Important Research octane number, indication of the knock resist- ance of petrol. The information in the vehicle documentation always has ...
Page 255: Vehicle Identification Data
Description of specifications Vehicle identification data left-hand side of the vehicle in the lower area of the windscreen. It is also located on the right hand side of the engine compartment. The most important information is given on the identifica- Vehicle data tion plate and the vehicle data sticker.
Page 256: Information On Fuel Consumption
Description of specifications Information on fuel consumption Weights Kerb weight refers to the basic model with a fuel tank filled to 90% capacity Fuel consumption and without optional extras. The figure quoted includes 75 kg to allow for the weight of the driver. The consumption and emission details shown on the vehicle For special versions and optional equipment fittings or for the addition of data sticker differ from one vehicle to another.
Page 257: Wheels
Description of specifications Drawbar load Snow chains The maximum permitted drawbar load on the ball joint of the towing bracket Snow chains may be fitted only to the front wheels, and only for the follow- must not exceed 75 kg. ing tyres: In the interest of road safety, we recommend that you always tow approach- 175/70R14...
Page 258: Technical Specifications
Technical specifications Technical specifications Checking fluid levels Overview You will find further explanations, instructions and restrictions on the tech- nical specifications as of ⇒ p age 252. From time to time, the levels of the different fluids in the ve- hicle must be checked.
Page 259: Petrol Engine 1.2 51 Kw (70 Ps)
Technical specifications Petrol engine 1.2 51 kW (70 PS) Engine specifications Power output in kW (PS) 51 (70)/ 5400 Maximum torque in Nm at rpm 112/ 3000 No. of cylinders/capacity in cm 3/ 1198 Fuel Super 95 RON /Normal 91 RON Research Octane Number = Anti-detonation rating of the petrol.
Page 260: Petrol Engine 1.4 63 Kw (85 Ps)
Technical specifications Petrol engine 1.4 63 kW (85 PS) Engine specifications Power output in kW (PS) 63 (85)/ 5000 Maximum torque in Nm at rpm 132/ 3800 No. of cylinders/capacity in cm 4/ 1390 Fuel Super 95 RON /Normal 91 RON Research Octane Number = Anti-detonation rating of the petrol.
Page 261: Petrol Engine 1.2 Tsi 77 Kw (105 Ps)
Technical specifications Petrol engine 1.2 TSI 77 kW (105 PS) Engine specifications Power output in kW (PS) 77 (105)/5000 Maximum torque in Nm at rpm 175/1550-4100 No. of cylinders/capacity in cm 4/ 1197 Fuel Super 95 RON /Normal 91 RON Research Octane Number = Anti-detonation rating of the petrol.
Page 262: Petrol Engine 1.2 Tsi 77 Kw (105 Ps) Start-Stop
Technical specifications Engine oil capacity Approximate engine oil capacity with oil filter change 3.6 litres  Petrol engine 1.2 TSI 77 kW (105 PS) Start-Stop Engine specifications Power output in kW (PS) 77 (105)/ 5000 Maximum torque in Nm at rpm 175/1550-4100 No.
Page 263: Petrol Engine 1.4 Tsi 110 Kw (150 Ps)
Technical specifications Engine oil capacity Approximate engine oil capacity with oil filter change 3.6 litres  Petrol engine 1.4 TSI 110 kW (150 PS) Automatic Engine specifications Power output in kW (PS) 110 (150)/ 5800 Maximum torque in Nm at rpm 220/ 1250-4500 No.
Page 264: Diesel Engine 1.2 Tdi Cr 55 Kw (75 Ps) Dpf Start-Stop Ecomotive
Technical specifications Engine oil capacity Approximate engine oil capacity with oil filter change 3.6 litres  Diesel engine 1.2 TDI CR 55 kW (75 PS) DPF Start-Stop Ecomotive Engine specifications Power output in kW (PS) 55 (75)/ 4200 Maximum torque in Nm at rpm 180/ 2000 No.
Page 265: Diesel Engine 1.2 Tdi Cr 55 Kw (75 Ps) Dpf
Technical specifications Engine oil capacity Approximate engine oil capacity with oil filter change 4.1 litres  Diesel engine 1.2 TDI CR 55 kW (75 PS) DPF Engine specifications Power output in kW (PS) 55 (75)/ 4200 Maximum torque in Nm at rpm 180/ 2000 No.
Page 266: Diesel Engine 1.6 Tdi Cr 66 Kw (90 Ps) Dpf
Technical specifications Engine oil capacity Approximate engine oil capacity with oil filter change 4.1 litres  Diesel engine 1.6 TDI CR 66 kW (90 PS) DPF Engine specifications Power output in kW (PS) 66 (90)/ 4200 Maximum torque in Nm at rpm 230/ 1500-2500 No.
Page 267: Diesel Engine 1.6 Tdi Cr 77 Kw (105 Ps) With/Without Dpf
Technical specifications Engine oil capacity Approximate engine oil capacity with oil filter change 4.3 litres  Diesel engine 1.6 TDI CR 77 kW (105 PS) with/without DPF Engine specifications Power output in kW (PS) 77 (105)/ 4400 Maximum torque in Nm at rpm 250/ 1500-2500 No.
Page 268 Technical specifications Engine oil capacity Approximate engine oil capacity with oil filter change 4.3 litres ...
Page 269: Dimensions And Capacities
Technical specifications Dimensions and capacities Dimensions Length, width 4236 mm/ 1693 mm Height at kerb weight (with bars) 1445 mm Front and rear projection 857 mm/ 910 mm Wheelbase 2469 mm Turning circle 10.7 m Front Rear Track width 1465 mm 1457 mm Capacities Fuel tank...
Page 271: Index
Index Index Anti-lock brake system ....168 Belt tensioners ......28 Warning lamp .
Page 272 Unlocking ......82 Child seat ......45 Controls Cetane number .
Page 273 Emission control system senger seat ......31 side light ......236 Warning lamp .
Page 274 Instrument and switch lighting ... . . 99 Front seat adjustment HBA ........167 Instrument lighting .
Page 275 Index Maintenance One-touch opening and closing Airbags ......32 Electric windows ..... . 93 Keys .
Page 276 Control lamp ......97 Seat belts ......19 Rubber seals .
Page 277 Underbody protection ....185 front seat ......121 Towing .
Page 278 Maintenance ......183 Why wear seat belts? ....19, 21, 30 Products for vehicle maintenance .
Page 279 SEAT S.A. is permanently concerned about continuous development of its types and models. For this reason we ask you to under- stand, that at any given time, changes regarding shape, equipment and technique may take place on the car delivered. For this reason no right at all may derive based on the data, drawings and descriptions in this current handbook.

Seat IBIZA ST Owner's Manual

Manual Structure

Content

Safety First

Operating Instructions

Panorama Tilting Sunroof* . . . . . . . . . . . . . . . . . . 95 Practical Tips

Technical Specifications

Technical Specifications

Index

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seat IBIZA ST

Summary of Contents for Seat IBIZA ST

Table of Contents
