Craftex CX Series Owner's Manual

13 inch x 24 inch metal lathe
Hide thumbs Also See for CX Series:
Table of Contents

Advertisement

Quick Links

See also: User Manual , Manual
C X 7 0 9
1 3 " X 2 4 " ME T A L L A T H E
O WN E R ' S MA N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CX Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Craftex CX Series

Summary of Contents for Craftex CX Series

  • Page 1 C X 7 0 9 1 3 ” X 2 4 ” ME T A L L A T H E O WN E R ’ S MA N U A L...

  • Page 2: General Safety Instructions

    GENERAL SAFETY INSTRUCTIONS EXTREME CAUTION SHOULD BE USED IN OPEATION ALL POWER TOOLS. KNOW YOUR POWER TOOL, BE FAMILIAR WITHITS OPEARTION. READ THE OWNER’S MANUAL AND PRACTICE SAFE USAGE PROCEDURES AT ALL TIMES. ◆    CONNECT your machine ONLY to the matched and specified power source. ◆...

  • Page 3: Specifications

    BL330E PRECISION GEAR HEAD LATHE As part of the growing line of metalworking equipment, we are proud to offer the BL330E Metal Lathe. The name guarantees ANHUI PAN-SINO. By following the instructions and procedures laid out in this owner’s manual, you will receive years of excellent service and satisfaction. The BL330E is a professional tool and like all power tools, proper care and safety procedures should be adhered to.
  • Page 4 Illustrated Features         Fig 1. Driving system drawing.   01. Input Pulley 21. Gear 02. Gear Change 22. Gear 03. Gear Change 23. Gear 04. Gear Change 24. Worm Gear 05. Gear Change 25. Worm 06. Gear 26.
  • Page 5 Lifting ＆ Installation It is recommended that this machine is lifted by the use of a crane or hoisting mechanism as it is very heavy.   Fig 2. Lifting drawing. Lifting ＆ Installation Please refer to figure 3 when installing this machine. As this lathe is for the most part pre-assembled at the factory, there is not a great deal of assembly for the end user.
  • Page 6 Lubrication Positions   Fig 4. Lubrication positions drawing. Refer to the Lubrication chart on the following page in order to properly lubricate and maintain your Lathe. Proper lubrication of any tools, especially Metal Lathes should not be ignored.   Lubrication Positions No. ...
  • Page 7 Electrical System Drawing Grounding Instructions In the event of a malfunction or breakdown, grounding provides the path of least resistance for electrical current and reduces the risk of electrical shock. This tool is equipped with an electrical cord that has an equipment grounding conductor and a grounding plug. The plug MUST be plugged into a matching outlet that has been properly installed and grounded in accordance with ALL local codes and ordinances.
  • Page 8 If in doubt about these instructions consult a qualified, licensed electrician. USE ONLY A THREE-WIRE EXTENSION CORD with a 3-prong grounding plug. Threading Chart Cutting threads can be performed by the manual use of the change gears and handle (refer to Operating Controls) Threading Chart Please see the following diagram for reference to cutting threads...

  • Page 9: Operating Controls

    Operating Controls SUMMARY: REFER TO THE DIAGRAM BELOW FOR THE BL330E operation controls.     4                          5            6              7                  8                9          10              11   ...
  • Page 10 Detailes:   Replacement of Chuck The head spindle holding fixture is cylindrical. Loose three set Screw/nut（A. Fig. 9）on the flange to remove the chuck Replace new chuck and fix it by the same set screws and nuts. Fig.9 Replacement of Chuck Jaw 5The jaws are in two types –...
  • Page 11 Straight Turning In the straight turning operation, the tool feeds parallel to the axis of rotation of the workpiece. The feed can be either manual by turning the handwheel on the lathe saddle or the top slide, or by activating the automatic feed. The cross feed for the depth of cut is achieved using the cross slide.
  • Page 12 Taper Turning by Setting top Slide By angle the top slide, tapers may be turned manually with the Top slide ( Fig. 18 ). Rotate the top slide to the required angle. A graduated scale permits accurate adjustment of the top slide. The cross feed is performed with the cross slide.
  • Page 13 Adjustment After a period time, wear in some of the moving components may need to be adjusted. Compound Rest Adjustment Loosen the two screws (A. Fig. 20), after you have obtained The angle you want, do not forget to tighten them again. Belt Adjustment Loosen the two nuts and screws (A.
  • Page 14 Parts Diagram- Headstock      ...
  • Page 15 Parts Listing- Headstock NO.   Parts No.  Description  1  V700 GB/T1171‐1986  V‐belt type 700  2  M16*1.5 GB/T812‐1988  Spanner nut  3  16 GB/T858‐1988  Lock washer for circular nut  4  BL330‐02013  Spindle pulley  5  6206/P6 GB/T276‐1994  Taper roller bearing  6  M5*16 GB/T77‐1985  Hexagon socket head screw  7  BL330‐02015  Pulley seat  8  FB016030 GB/T13871‐1992  Felt cover  9  M6*8 GB/T818‐1985  Crossrecessed pan head screws  10  6 GB/T97.1‐1985  Plain washers  11  BL330‐02011  Lathe head  15 ...
  • Page 16 37  BL330‐02041  Washer  38  11.2*2.65 GB/T3452.1‐1992  O‐seal ring  39  BL330‐02039b  Right Block  40  A10 JB/T9741.2  Oil Sight  41  BL330‐02036a  Sleeve  42  12 GB/T894.1‐1986  C‐Clip  43  BL330‐02038a  Left shifting fork  44  BL330‐02037  Shifting fork shaft  45  BL330‐02038b  Right shifting fork  46  BL330‐02036b  Sleeve  47  M10 GB/T41‐1986  Nut  48  10 GB/T97.1‐1985  Plain washers  49  BL330‐02029  Gear 24T  50  FB016030 GB/T13871‐1992 ...
  • Page 17 72  28 GB/T894.1‐1986  C‐Clip  73  M50*1.5 GB/T812‐1988  Spanner nut  74  50 GB/T858‐1988  Lock washer for circular nut  75  M5*16 GB/T77‐1985  Hexagon socket head screw  76  BL330‐02045  Sleeve  77  BL330‐02046  Pressurize washer  78  BL330‐02044  Sleeve spacer  79  32010/P6X GB/T276‐1994  Taper roller bearing  80  55 GB/T894.1‐1986  C‐Clip  81  BL330‐02048  Gear 56T  82  32012/P5 GB/T276‐1994  Taper roller bearing  83  BL330‐02049  Pressurize washer  84  BL330‐02050  Main shaft bearing oil seal  85  BL330‐02047 ...
  • Page 18 Parts Diagram- Trestle  ...
  • Page 19 Parts Listing- Trestle   NO.   Parts No.  Description  1  8 GB/T7940.4‐1995  Oil cup  2  BL330‐07015  Apron body    3  8*30 GB/T118‐1986  Taper pins  4  M8*100 GB/T70‐1985  Hexagon socket head screw  5  BL330‐02043  Handle lever  7  BL330‐07013  Right shifting fork  8  BL330‐07012  Shaft  9  BL330‐07011  Base   10  M5*12 GB/T819‐1985  Screw  11  5*50 GB/T117‐1986  Taper pins  12 ...
  • Page 20 34  4*12 GB/T1096‐1994  Key  35  BL330‐07016  Shaft  36  5*35 GB/T1096‐1994  Key  37  BL330‐07019a  Gear 20T  38  BL330‐07020  Sleeve spacer  39  BL330‐07019b  Gear 20T  40  Φ2.5*24  Shaft  41  BL330‐08020  Shaft  42  BL330‐08021  Sleeve    43  BL330‐08019  Gear 25T  44  BL330‐08019  Gear 50T  45  BL330‐08022  Sleeve    46  5*20 GB/T1096‐1994  Key ...
  • Page 21 Parts Diagram- Bed  ...
  • Page 22 Parts Listing- Bed   NO.   Parts No.  Description  1  M5*12 GB/T77‐1985  Hexagon socket head screw    BL330‐09014  Cam sleeve  3  BL330‐09015  Switch bar  4  BL330‐09016  Connecting plate  5  5 GB/T96‐1985  Plain washers  6  M5 GB/T41‐1986  Nut  7  BL330‐09017  Shield  8  BL330‐01017  Shield  9  M6*10 GB/T77‐1985  Hexagon socket head screw  10  12 GB/T96‐1985  Plain washers  11  M12*45 GB/T5783‐2000  Hexagon head screw ...
  • Page 23 33  6 GB/T7940.4‐1995  Oil cup  34  BL330‐05017  Cross feed screw seat  35  M5*55 GB/T77‐1985  Hexagon socket head screw  36  BL330‐03021  Spring lamination  37  BL330‐03022  Dial sleeve  38  4*25 GB/T117‐1986  Taper pins  39  BL330‐05024  Handles with sleeve  40  M12*1.25 GB/T812‐1988  Spanner nut  41  BL330‐05016  Dial    42  51101 GB/T301‐1995  Rolling bearing  43  BL330‐05018  Cross nut  44  BL330‐05020  Chain up block  46  BL330‐05014  Behind board  47 ...
  • Page 24 Parts Diagram- Apron  ...
  • Page 25 Parts Listing- Apron   NO.   Parts No.  Description  1  M10 GB923‐1988  Domed cap nuts  2  10 GB/T923‐1976  Spring washer  3  JB/T7270.4‐1994  Sleeve  4  B12*125 JB/T7273.3‐1994  Hand wheel  5  BL330‐03022  Sleeve  6  BL330‐03021  Spring lamination  7  BL330‐06030  Dial  8  M4*16 GB70‐85  Hexagon socket head screw  9  BL330‐06029  Flange sleeve  10  4*30 GB/T1096‐1994  Pin  11  BL330‐06028  Gear shaft ...
  • Page 26 37  BL330‐06022  Gear shaft  38  BL330‐04‐015  Chock  39  BL330‐04‐014  Screw nut  40  6*12 GB/T119‐1986  Column pins  41  BL330‐04‐016  Shaft  42  M5*35 GB/T70‐1985  Hexagon socket head screw  43  BL330‐04‐033  Apron body right cover  44  BL330‐04‐013  Cover  45  M4*8 GB  Screw  46  12 GB/T894.1‐1986  C‐Clip  47  BL330‐06038  Gear 30T  48  4*12 GB/T1096‐1994  Pin  49  BL330‐06037  Axis  50  BL330‐06039 ...
  • Page 27 Parts Diagram-Tailstock                  ...
  • Page 28 Parts Listing- Tailstock NO.   Parts No.  Description  1  MT3#  Rolling center  2  BL330‐03012  Tailstock center sleeve  3  BL330‐03013  T‐Key  4  BL330‐03019  Tailstock Nuts  5  M4*10 GB/T78‐1985  Set screws with cone point  6  BL330‐03029  Locking nuts  7  BL330‐03029  Locking Sleeve  8  BL330‐03030  Handle seat  9  BL330‐02043  Handle lever  10  6 GB/T7940.4‐1995  Oil cup  11  BL330‐03011  Tailstock  12 ...
  • Page 29   Parts Diagram-Change Gear Box         Parts Listing- Change Gear Box...
  • Page 30   NO.   Parts No.  Description  1  A8*30 GB/T1096‐1994  Plain parallel key  2  Y90‐L4 B5 1.1KW  Motor 1.1kw  3  8*32 JB/T7274.4‐1994  Start‐grip knob  4  3*14 GB/T879‐1986  Taper pins  5  M5*8 GB/T819‐1985  Screw  6  BL330‐09013  Safe box  7  BL250B‐08037  Shaft  8  BL250B‐08049  Door‐knob  9  BL330‐08013  Compound box  10  BL330‐08027  Thread table  11  2.5*5 GB/T827‐1986  Rivet   12  BL330‐07014 ...
  • Page 31 DYILY INSPECTION In principle the daily. Inspection lathe is carried out on basis of each shift. The inspection work according to the following item 1-1 Check before starting the motor. 1) Clean-up of machine: Dust, chips and other articles should be removed from sliding surface of machine to make the rotating or sliding parts performing easy and smoothly.
  • Page 32 Check after operation: 1) Cleaning and collection of all tools: All tools should be kept clean first then put back to original position (tool cabinet) 2) Proper position of tailstock, carriage, ＆ tool holder: Tailstock, carriage, ＆ tool holder should be placed to proper position. 3) Clean-up of machine: All of the oily matters, chips etc, on the machine should be removed completely and put a thin lubricating oil on the sliding surface of machine to prevent the corrosion.
  • Page 33     3. Standard Accessories Name Quantity Ф160mm Self-center 3 jaw chuck 1set Dead center MT 3# 1set 4mm 1pc 5mm 1pc Inner hexagonal wrench 6mm 1pc 8mm 1pc 8-10mm 1pc Head wrench 12-14mm 1pc 17-19mm 1pc Wrench for tool post Change gears 13pcs Oil gun...
