3-8

Chapter 3:

Software

Versioning

User's Manual Pub. 0300309-01 Rev. A

Configuring the Micro800 Expansion I/O 2085-OX32-SC Using CCW

The software version tracks major and minor revisions for end users.

The shipped software version begins at version 1.1.

Once released, the major revision is typically incremented if new features are

introduced to the product. Otherwise only the minor revision is incremented.

In-field updating of the software by the end user is not supported.

During startup, all outputs are OFF until valid communications with the

Controller has been established and the Controller has been placed in Run mode.

There is no input data communication and no signal outputting before the

controller goes into Run mode. All channels are OFF if the module in not in Run

mode. User output controls are only loaded or re-loaded when Run mode is

detected. With the controller in Run mode, and no-fault state in the module, the

module sets the appropriate output channel to the state specified in the output

variables where 1=ON, and 0=OFF as Boolean data type control. If a hardware

fault is detected, all outputs are turned OFF, and the status variables indicate the

last module and channel status.
