The state of each output channel is displayed on the front panel LEDs.
All outputs have fault tolerance and ESD protection to avoid damage to circuitry
on the board. The modules use 50 VAC working Reinforced Insulation between
the output channels and the backplane, and between the output and the Chassis
GND. 50 V working Basic Insulation is provided for group-to-group isolation.
Each output channel can be directly controlled via Rockwell-provided Connected
Component Workbench (CCW) software for Micro850 and Micro870 family
controllers once the controller is in run mode. Pre-channel configuration is not
required.
The module is tested before shipping. After installation, during startup, devices
begin operation in a useable condition without a requirement for pre-channel
configuration. The module begins operation with all outputs off. The module
normally requires no further user intervention. However, if the module
experiences a hard fault condition, you may need to cycle power or pull the
module from the rack.

Output Specifications

The 2085-OX32-SC modules have the following output specifications:
Table 1-1. Output/Performance/Environmental Requirements
Output Description
Operating Temperature
Storage/Non-Operating
Temperature
Operating Humidity
Storage/Non-Operating Humidity
Vibration/Operating
Operating Shock
Storage/Non-Operating Shock
Pollution Level
Outputs per module
12/24 VDC customer supply
voltage
ON-state voltage
ON-State Voltage Drop
ON-state current
•
For the 2085-OV32-SC, the switch close is between the channel output
pin and the GROUND return pin on the terminal block.
Value
-20 ºC to 65 ºC (-4 ºF to 149 ºF)
-40 ºC to 85 ºC (-40 ºF to 185 ºF)
5% to 95%, non-condensing
5% to 85%, non-condensing
10 Hz to 500 Hz, 2 G, 0.030 max peak-to-peak
25 G, peak acceleration, 11 ms pulse, half sine
25 G peak acceleration, (35 G for panel mount), 11 ms pulse,
half sine
Meets Pollution Degree 2 requirements.
32
10.5 VDC minimum, 30 VDC maximum
10 VDC minimum ON under all conditions
24 VDC nominal under all conditions
30 VDC maximum
Less than 0.5 VDC maximum
1 mA minimum at 10 VDC
0.5 A maximum steady state (8 A per channel group)
Chapter 1: Module Overview
User's Manual Pub. 0300309-01 Rev. A
1-3
