Polycom® RSS™ 4000 Getting Started Guide – Version 7.0
Parameter
Enable IPv6
Obtain an IP Address
Automatically (IPv6)
Using the following IP
Address (IPv6)
Enable ICMP V6 DAD
Enable ICMP Echo
LAN Speed
9
Table 1-2
Parameter
Enable Destination
Unreachable Message
Host Name
Domain
Gateway
Default IPv6 Gateway
6
Description
Specifies whether to enable IPv6 related functions.
Specifies whether to obtain the IPv6 address automatically using
Stateless Address Auto-configuration (SLAAC).
Selects this option to manually configure a static IPv6 address. You
need to enter the link local address, site local address and global
address.
Specifies whether to enable the Duplicate Address Detection (DAD)
to ensure the IPv6 address set to the system is unique in the local
network.
Specifies whether to enable the system to respond to an ICMP echo
request (Ping) sent from other devices in the network. In some
high-security environments, you may need to disable this option to
protect the system from Ping attacks.
Specifies the speed/duplex modes for LAN port. Supports the
10/100M Full Duplex or Half Duplex mode and the 1000M network.
Select Auto to use auto-negotiation.
Note: When setting LAN port speed, contact your network
administrator to ensure that the switch link rate matches the system
port speed.
In the General System Network Settings area, configure the following settings.
General System Network Parameters Description
Description
Specifies whether to enable the system to forward ICMP destination
unreachable messages that come from other network devices when
the system is configured to serve as a router.
Specifies the host name of the system.
Specifies the domain name of the system.
Specifies the address of the interface to use for accessing the IPv4
gateway.
Specifies the address of the interface to use for accessing the IPv6
gateway.
