LED indicating the status of communication with the control panel:
ON – no communication with the control panel,
blinking – communication with the control panel OK.
Description of terminals:
- +12 V DC dedicated power supply output for CA-64 ADR-MOD addressable
POW
modules and detectors.
- common ground.
COM
- data input from CA-64 ADR-MOD addressable modules.
INT
ZA, ZB - terminals for future applications.
- tamper input (NC) – if not used, it should be shorted to the common ground.
TMP
- clock (expander communication bus).
CLK
- data (expander communication bus).
DAT
- +12 V DC power input / output.
+12V
Do not connect power to the terminals, if the dedicated power supply unit is
connected to the connector on electronics board.
- RS-485 bus.
A, B

3. DIP-switches

The DIP-switches 1-5 are used for address setting. A numerical value is assigned to each
switch. In OFF position, the value is 0. Numerical values assigned to individual switches in
ON position are shown in Table 1. The sum of numerical values assigned to switches 1-5
means the address set on the module. The address must be different from that on the other
modules connected to the communication bus of the control panel.
DIP-switch number
Numerical value
The switch 10 allows you to define how the expander will be identified by the control panel
(see: Table 2) and how many addresses it will take up in the system. If the switch is set to the
ON position, the expander will take up 6 addresses (the address set in the expander and 5
subsequent ones). At the same time, 48 zones will be reserved in the system for the
expander. If the switch is set to the OFF position, the expander can take up from 1 to 6
addresses and at the same time reserve from 8 to 48 zones (1 address = 8 zones). The
number of occupied addresses and reserved zones depends on the number of connected
addressable modules and addresses set in them (see: Table 3). Consecutive sequence of
addresses must be maintained and any gaps must be avoided, because one module with an
address out of a group of 8 addresses suffices to reserve 1 address and 8 zones.
DIP-switch position
INT-ADR
Table 1.
expander w/o power supply
ON
INT-ADR
OFF
Table 2.
1
2
3
1
2
4
Identification of device
expander with power supply
INT-ADRPS / CA-64 ADR
INT-ADRPS / CA-64 ADR
4
5
8
16
SATEL
