Table 1-1. Pin out description (Continued)
QFN32 Pin
Number Mnemonic
2 PD3
12 PD4
13 PD5
14 PD6
15 PD7
31 PE0
10 PE1
11 PE2
Note: 1. On the first engineering samples (Parts marked AT90PWM324), the ACMPN3 alternate
function is not located on PC4. It is located on PE2.
Atmel ATmega16/32/64/M1/C1
Type Name, Function and Alternate Function
TXD (UART Tx data)
TXLIN (LIN Transmit Output)
OC0A (Timer 0 Output Compare A)
I/O
SS (SPI Slave Select)
MOSI_A (Programming & alternate Master Out SPI Slave In)
PCINT19 (Pin Change Interrupt 19)
ADC1 (Analog Input Channel 1)
RXD (UART Rx data)
RXLIN (LIN Receive Input)
I/O
ICP1A (Timer 1 input capture alternate A input)
SCK_A (Programming & alternate SPI Clock)
PCINT20 (Pin Change Interrupt 20)
ADC2 (Analog Input Channel 2)
I/O ACMP2 (Analog Comparator 2 Positive Input)
PCINT21 (Pin Change Interrupt 21)
ADC3 (Analog Input Channel 3)
ACMPN2 (Analog Comparator 2 Negative Input)
I/O
INT0 (External Interrupt 0 Input)
PCINT22 (Pin Change Interrupt 22)
ACMP0 (Analog Comparator 0 Positive Input)
I/O
PCINT23 (Pin Change Interrupt 23)
RESET (Reset Input)
I/O or I OCD (On Chip Debug I/O)
PCINT24 (Pin Change Interrupt 24)
XTAL1 (XTAL Input)
I/O OC0B (Timer 0 Output Compare B)
PCINT25 (Pin Change Interrupt 25)
XTAL2 (XTAL Output)
I/O ADC0 (Analog Input Channel 0)
PCINT26 (Pin Change Interrupt 26)
