Bartell Innovatech Terminator Infinity 2.0 Manual page 36

Item No. Part Number
1801 31-0271
1802 31-0272
1803 31-0273
1804 31-0274
1805 31-0277
1806 31-0278
1807 31-0291
1808 31-0292
Infinity 2.0 Hydraulics
Description
Infinity Hose Assembly, L Valve to Upper Jaw
Infinity Hose Assembly, Valve to Wheel
Infinity Hose Assembly, L Valve to Filter
Infinity Hose Assembly, L Valve to Lower Jaw
Infinity Hose Assembly, R Valve to Filter
Infinity Hose Assembly, Filter to Tank
Infinity Hose Assembly, Pump to Valve
Infinity Hose Assembly, Tank to Pump
P a g e
OIPB-I01029-Infinity2.0_v1.2
| 36
Qty.
1
4
1
1
1
1
2
1
