Bartell Innovatech Terminator Infinity 2.0 Manual page 34

Infinity 2.0 Battery Pack - Part # 71-0033
Item No. Part Number
1701 12-0018-06
1702 12-0020
1703 12-0021-06
1704 12-0035-06
1705 12-0043-16
1706 23-0141
1707 24-0032
1708 24-0033
1709 24-0216
1710 24-0219
1711 24-0234
1712 25-0103
1713 25-0104
1714 51-1079
1715 53-0241
1716 81-0672
Description
Lock Washer, M6
Socket Head Cap Screw, M6-1.0 x 30mm
Nyloc Nut, M6-1.0
Flat Washer, M6
Serrated Flange Cap Screw, M6-1.0 x 16mm
AGM Battery, 6V 400Ah
Battery Pack Wire Assembly, 13.5"
Battery Pack Wire Assembly, 11"
Infinity Wire Assembly, Back Charger to Negative
Infinity Wire Assembly, Back Charger to Positive
Infinity 2.0 Wire Assembly, Blue Plug Batt. Pigtail
Battery Boot, Red
Battery Boot, Black
AMG Battery Shim
Removable Battery Tray
Infinity Secondary On-board Charger
P a g e
OIPB-I01029-Infinity2.0_v1.2
| 34
Qty.
2
2
4
4
8
8
1
6
1
1
1
8
8
4
1
1
