Bartell Innovatech Terminator Infinity 2.0 Manual page 31

Infinity Right Wheel Assembly - Part # 96-0382
Item No. Part Number
1401 11-0013
1402 11-0028
1403 11-0029
1404 11-0228
1405 11-0230
1406 13-0021
1407 13-0022
1408 31-0053
1409 33-0003
1410 51-0491
1411 53-0208
1412 70-0016
Description
Hex Head Cap Screw, 1/2"-13 x 3"
Nyloc Nut, 1/2"-13
Nyloc Nut, 1/2"-20
Hex Head Cap Screw, 1/2"-13 x 5"
Flat Washer, 1/2"
Right Brake Caliper
Brake Mounting Bracket
Hydraulic Fitting, 90 deg 8 JIC – 10 SAE
Right Wheel Motor
Brake Spacer Standoff
Wheel and Tire Assembly
Wheel Hub with Brake Disc
P a g e
OIPB-I01029-Infinity2.0_v1.2
| 31
Qty.
2
4
5
2
5
1
1
2
1
2
1
1
