EDGER TROWEL
B424
B430
375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201
200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728 732-566-5400 FAX 732 -566-5444
BARTELL MORRISON INC.
BARTELL MORRISON (USA) LLC
Doc. # OI-B09002
Orig. Rel. - 07-2004
Created: 07/04
Curr. Rev. - 12
Revised: 08/14
Rev. Date - 08-2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B424 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bartell B424

Summary of Contents for Bartell B424

  • Page 1 EDGER TROWEL B424 B430 BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201 Doc. # OI-B09002 200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728 732-566-5400 FAX 732 -566-5444 Orig. Rel. - 07-2004 Created: 07/04 Curr.
  • Page 2 Failure to follow operating instructions could result in serious injury or death. BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 2 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 2 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201...

  • Page 3: Table Of Contents

    ELECTRIC EDGER START-UP ..........................1. EDGER TROWEL ASSEMBLY (FIGURE 1) ................12 ELECTRIC EDGER WIRING DIAGRAM ........................EDGER TROWEL PARTS LIST - B424 ..................14 ASSEMBLY DRAWINGS AND PARTS LIST ......................2. SPIDER PLATE ASSEMBLY (FIGURE 2) .................. 16 1. EDGER POWER TROWEL FULL ASSEMBLY TOP (DRAWING) ...............

  • Page 4: Quality Assurance/Machine Break-In

    We thank you for the confidence you have placed in us by purchasing a Bartell Edger Power Trowel and wish you many years of satisfied use.

  • Page 5: Edger Power Trowel Warranty

    Under no circumstances shall Bartell Morrison Inc. be liable for any additional or exceptional costs beyond the cost to repair or replace the defective portion of the equipment. Bartell Morrison Inc. shall not be held accountable for; costs associated with travel to inspect or repair defective equipment, costs for transporting defective equipment to or from an authorized repair facility, costs incurred to repair or replace the defective equipment at any facility other than one authorized by Bartell Morrison Inc., or ancillary...

  • Page 6: Maintenance Record

    However, when in need of parts or major service, be sure to see your Bartell Morrison dealer. For your convenience we have provided this space to record relevant data about your Edger Power Trowel.

  • Page 7: Routine Service Intervals

    Gearbox oil Check Level Change Gearbox breathers Check operation BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 7 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 7 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201...
  • Page 8 ¥ Failure to have your Edger Power Trowel regularly serviced and properly maintained in accordance with the manufacturer’s instructions will lead to premature failure and void the warranty. BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 8 - BARTELL MORRISON INC.

  • Page 9: Foreword

    EDGER TROWEL INSTRUCTION MANUAL FOREWORD IMPORTANT: The Bartell Edger Power Trowel, also known as a Mini- Before running machine with belt installed, ensure trowel/Edger, has been developed to float and finish the that engine idles properly and that the safety-switch edges of concrete floors, up to perimeter walls, around shuts off the engine.

  • Page 10: Starting Procedure - Warm Climate

    Remove the float disc when lifting machine more than 100cm (40in). The floating disc could fall off. BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 10 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 10 -...

  • Page 11: Storage

    12 AWG 12-16 14 AWG 12 AWG (NOT RECOMMENDED) BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 11 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 11 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201...
  • Page 12 Edger Edger Edger Edger BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 12 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201 200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728 732-566-5400 FAX 732 -566-5444 Created: 07/04 Revised: 08/14...
  • Page 13 EDGER TROWEL INSTRUCTION MANUAL EDGER Edger EDGER BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 13 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201 200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728 732-566-5400 FAX 732 -566-5444 Created: 07/04...
  • Page 14 4. Brace your hip against the shield pad on the handle for better control. Bartell Electric Power Trowels operate at a constant speed which is achieved immediately after startup, so there will be some kick.
  • Page 15 SAFETY SWITCH CONTROL BOX 375 ANNAGEM BLVD., MISSISSAUGA, ONTARIO, CANADA L5T 3A7, 905-364-4200 FAX 905-364-4201 BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 15 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201 CREATED: 07/04 200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728 732-566-5400 FAX 732 -566-5444...
  • Page 16 This will help prevent rust during storage. Replace spark plug. 5. Store the unit in an upright position in a cool, dry, well ventilated area. BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 16 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 11 -...
  • Page 17 ASSEMBLY DRAWINGS AN D PARTS D PARTS ASSEMBLY DRAWINGS AN LIST LIST BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 17 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 12 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201...
  • Page 18 EDGER TROWEL ASSEMBLY EDGER POWER TROWEL ASSEMBLY Figure 1 - Full Top Assembly Figure 1 - Complete Edger Trowel BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 18 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 13 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201...
  • Page 19 6/8/2004 Continued on next page…  - 19 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 14 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201...
  • Page 20 Retaining Ring, 5100-0031 6/8/2004 Continued on next page…  BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 20 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 14 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201...

  • Page 21: Spider Plate Assembly (Drawing And Parts List)

    6/8/2004 Continued on next page…  - 21 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 14 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201...
  • Page 22 EDGER TROWEL INSTRUCTION MANUAL SPIDER PLATE ASSEMBLY EDGER POWER TROWEL ASSEMBLY Figure 3 - Oil-Bath Spider Plate Assembly B424 - 21616, B430 - 11815 Item # B424 B430 Description Qty. Eff. Date 11757 11757 Oil Lubricated Spider Plate 1/1/1997 11754...
  • Page 23 Figure 3 - Folding Handle Assembly Not Part of 21632 Figure 4 - Folding Handle Assembly Figure 1 - Complete Edger Trowel BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 23 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 13 -...
  • Page 24 2/1/2008 11853 Bracket, Lower 2/1/2008 BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 24 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201 200 COMMERCE DRIVE, FREEHOLD, NEW JERSEY, USA, 07728 732-566-5400 FAX 732 -566-5444 Created: 07/04...

  • Page 25: Troubleshooting

    Gearbox malfunction Clutch seized ¥ ¥ Pulley out of alignment BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 25 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 19 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201...

  • Page 26: Specifications

    910 Shipping Dimensions 39” x 40” x 31” (1000 x 1020 m x 790 Shipping Weight 157 lbs (71 kg) ~ B424 192 lbs (87 kg) ~ B430 Blade Speed (RPM) 70 min – 125 max Engine Speed (RPM) 3600...
  • Page 27 2001/95/EC General Product Safety Directive 2002/95/EC Reduction of Hazardous Waste Directive BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 27 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 21 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201...
  • Page 28 Numero de serie da maquina Numero de serie do motor Massa Modello Numero di seria la macchina Numero di seria la motore Massa B424 Edger Power Trowel 125lbs (56.8kg) (kg) 148lbs B430 Edger Power Trowel B436 Walk Behind Power Trowel (67.1kg)
  • Page 29 EDGER TROWEL INSTRUCTION MANUAL NOTES BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 29 - BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC - 23 - 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201 375 ANNAGEM BLVD, MISSISSAUGA, ONTARIO, CANADA, L5T 3A7, 905-364-4200 FAX 905-364-4201...
  • Page 30 BARTELL MORRISON BARTELL MORRISON INC. BARTELL MORRISON (USA) LLC. 25 200 Commerce Dr. 375 Annagem Blvd. 12 Industrial Drive. Freehold, New Jersey, USA Mississauga, Ontario, Canada Keyport, New Jersey, USA 07728 L5T3A7 07735 Toll Free: 888-999-1570 Toll Free: 866-501-1683 Toll Free: 888-999-1570...
