Bartell Innovatech Terminator Infinity 2.0 Manual page 24

Item No. Part Number
701 11-0030
702 11-0034
703 12-0021-05
704 12-0021-08
705 12-0032-16
706 12-0041-12
707 12-0044-20
708 12-0050-16
709 13-0387
710 53-0391
711 53-0392
712 53-0393
713 53-0394
714 53-0395
715 96-0380
Hood Arm Breakdown
Description
Flat Washer, #10
Flat Washer, 5/16"
Nyloc Nut, M5-0.8
Nyloc Nut, M8-1.25
Hex Head Cap Screw, M8-1.25 x 16mm
Hex Head Cap Screw, M5-0.8 x 12mm
Serrated Flange Cap Screw, M8-1.25
Low Socket Cap Screw, M8-1.25 x 16mm
12" Lanyard
Uni-Frame Rear Side Support
Uni-Frame Rear Cross Support
Uni-Frame Hood Support
Top Cover Mounting Bracket
Uni-Frame Rear Support Bracket
Infinity Top Cover Assembly
P a g e
OIPB-I01029-Infinity2.0_v1.2
| 24
