Bartell Innovatech Terminator Infinity 2.0 Manual page 25

Rear Panels & Support Breakdown
Item No. Part Number
801 12-0043-16
802 12-0044-20
803 12-0045-20
804 51-1048
805 53-0373
806 53-0391
807 53-0392
808 53-0394
809 53-0395
810 53-0406
811 53-0415
Description
Serrated Flange Cap Screw, M6-1.0 x 16mm
Serrated Flange Cap Screw, M8-1.25 x 20mm
Flat Head Phillips Screw, M6-1.0 x 20mm
Uni-Frame Battery Guide, Rear
Uni-Frame Back Panel
Uni-Frame Rear Side Support
Uni-Frame Rear Cross Support
Top Cover Mounting Bracket
Uni-Frame Rear Support Bracket
Uni-Frame Battery Guide Spacer, Rear
Uni-Frame Side Panel
P a g e
OIPB-I01029-Infinity2.0_v1.2
| 25
Qty.
19
4
4
2
1
2
1
1
4
2
2
