Bartell Innovatech Terminator Infinity 2.0 Manual page 19

Item No. Part Number
201 11-0035
202 11-0045
203 11-0052
204 11-0236
205 12-0021-10
206 12-0034-40
207 13-0378
208 31-0043
209 34-0015
210 53-0117
211 96-0386
Front Exterior Breakdown
Flat Washer, 3/8"
Adjustable Clevis Pin, 5/8" x 3" L
Hitch Pin
Clevis Pin, 1/2" x 3" L
Nyloc Nut, M10-1.5
Hex Head Cap Screw, M10-1.5 x 40mm
Caster Wheel Replacement
Hydraulic Fitting, 90 deg 4 JIC – 8 SAE
Hydraulic Ram (90 deg)
Foot Rest, 1-piece
Pivoting Jaw Assembly
Description
OIPB-I01029-Infinity2.0_v1.2
P a g e | 19
Qty.
8
2
8
2
4
4
1
2
1
1
1
