Bartell Innovatech Terminator Infinity 2.0 Manual page 18

Item No. Part Number
101 11-0085
102 12-0018-06
103 12-0026
104 12-0043-16
105 13-0257
106 23-0155
107 53-0363
108 53-0370
109 53-0397
110 53-0418
111 96-0389
Front Panels & Seat Breakdown
Pan Head Phillips Screw, #6-32 x 1/2"
Lock Washer, M6
Hex Head Cap Screw, M6-1.0 x 12mm
Serrated Flange Cap Screw, M6-1.0 x 16mm
GT50 Seat w/ microswitch
Infinity Flanged Inlet Receptacle
Uni-Frame Assembly
Uni-Frame Front Side Panel
Uni-Frame Seat Mounting Bracket
Infinity Front Panel
Infinity Seat Platform Assembly
Description
OIPB-I01029-Infinity2.0_v1.2
P a g e | 18
Qty.
4
4
4
23
1
2
1
2
2
1
1
