Bartell Innovatech Terminator Infinity 2.0 Manual page 21

Item No. Part Number
401 11-0069
402 11-0092
403 12-0043-16
404 12-0045-20
405 31-0051
406 31-0282
407 31-0283
408 31-0284
409 35-0060
410 51-1050
411 53-0398
412 53-0399
413 53-0405
414 71-0033
Battery Area Breakdown
Description
Lock Washer, 1/4"
Hex Head Cap Screw, 1/4"-20 x 1/2"
Serrated Flange Cap Screw, M6-1.0 x 16mm
Flat Head Phillips Screw, M6-1.0 x 20mm
Hydraulic Fitting, 90 deg 12 JIC – 12 SAE
Hydraulic Fitting, Straight 6 JIC – 12 SAE
Hydraulic Fitting, Branch Tee 6 JIC – 12 SAE
Hydraulic Fitting, 90 deg 6 JIC – 6 JIC
Hydraulic Oil Filter Replacement
Uni-Frame Battery Guide, Front
Uni-Frame Filter Bracket
Uni-Frame Battery Stop
Uni-Frame Battery Guide Spacer, Front
Infinity 2.0 Battery Pack, AGM 48 VDC
P a g e
OIPB-I01029-Infinity2.0_v1.2
| 21
Qty.
2
2
6
4
1
1
1
1
1
2
1
2
1
1
