Bartell Innovatech Terminator Infinity 2.0 Manual page 22

Item No. Part Number
501 12-0018-10
502 12-0021-08
503 12-0021-10
504 12-0024
505 12-0032-16
506 12-0032-45
507 12-0034-40
508 12-0035-08
509 12-0035-10
510 24-0160
511 31-0281
512 31-0172
513 31-0286
514 31-0290
515 53-0435
Motor & Pump Breakdown
Lock Washer, M10
Nyloc Nut, M8
Nyloc Nut, M10
Hex Head Cap Screw, M10-1.5 x 30mm
Hex Head Cap Screw, M8-1.25 x 16mm
Hex Head Cap Screw, M8-1.25 x 40mm
Hex Head Cap Screw, M10-1.5 x 40mm
Flat Washer, M8
Flat Washer, M10
Infinity 2.0 Motor, 5.5HP
Hydraulic Fitting, 90 deg 12 JIC – 10 SAE
Hydraulic Fitting, 90 deg 6 JIC – 10 SAE
Hydraulic Fitting, Straight 6 JIC – 10 SAE
Infinity 2.0 Gear Pump, 6CC
Infinity 2.0 Motor Mount
Description
OIPB-I01029-Infinity2.0_v1.2
P a g e | 22
Qty.
2
1
2
2
3
1
2
5
6
1
1
1
1
1
1
