Bartell Innovatech Terminator Infinity 2.0 Manual page 30

Infinity Controls Bracket (L) - Part # 96-0384
Item No. Part Number
1301 12-0060
1302 12-0049-70
1303 12-0052
1304 13-0023
1305 13-0037
1306 13-0050-1
1307 31-0094
1308 31-0163
1309 31-0233
1310 31-0287
1311 35-0057
1312 53-0421
1313 53-0433
1314 53-0434
1315 13-0275
1316 12-0018-08
1317 32-0026
Description
Socket Head Bolt, M8-1.25 x 60mm
Hex Head Bolt, M8-1.25 x 70mm
Socket Head Cap Screw, M5-0.8 x 60mm
Brake Cable
Brake Cable Clevis
Modified Brake Lever
Hydraulic Fitting, 90 deg 8 JIC – 8 SAE
Hydraulic Fitting, Flow Reducer 4 JIC – 8 SAE
Hydraulic Fitting, Straight 6 JIC – 8 SAE
Hydraulic Fitting, Long 90 deg 8 JIC – 8 SAE
Two-Section Valve
Infinity Mounting Bracket (L)
Infinity Brake Spacer
Infinity Handle Collar
Hose Clamp
Lock washer, M8
Pivot Box, Infinity Valve
P a g e
OIPB-I01029-Infinity2.0_v1.2
| 30
Qty.
3
2
4
1
1
1
1
2
2
1
1
1
2
1
2
3
2
