Main Board

●
Main Board Connection / Installation Notes
The table below is the descriptions of the connectors of the main board.
Each connector/slot is used for the specified part or optional peripheral.
Please refer to the notes as below and examine the layouts of the main boards to locate
the correct connectors so as to complete the installation.
i.e.:
To connect the HDD to the main board, please use the HDD cable and locate the
matched connector on the main board; then connect the HDD cable to the Hard Drive.
No. Connector/Slot
1 HDD Connectors
Connector of Capacitive Touch
2
Control Unit.
3 Connector of Side I/O Board
Connector of Resistive Touch
4
Control Unit.
5 Connector of PWR Indicator
6 Connector of Power Switch
7 LVDS Connector
8
Audio Connector (Speaker)
9-1 Connector of Side I/O (MSR)
9-2 Connector of Side I/O (USB)
10 Inverter Connector
11
RAM Module Slot
12 CPU FAN Connector
Connection/Installation Notes
Please use the HDD cable and connect to the Hard
drive. (Black: Data; White: HDD power)
ONLY when connect to the Capacitive Touch Panel
Connect to the Side I/O Board (PS/2 and USB)
ONLY when connect to the Resistive Touch Panel
Connect the Power Indicator to the main board.
Connect the Power Switch to the main board.
Use the LVDS Cable and connect to the LCD Panel.
Connect the Speaker to the main board.
Connect the Side I/O Connector (MSR) to the main
board.
*Reserved for MSR/i-Button Module
Connect the Side I/O Connector (USB) to the main
board.
*Reserved for MSR/i-Button Module
Please use Inverter Cable and connect to the Inverter.
Install the RAM module to the main board.
Install the CPU Cooler kit(CPU Fan & Heat Sink)
*For POS-6000-I only
