Fametech POS-8717U Quick Installation Manual


Specifications
Model
Processor
Intel® Core™ i5-7267U Processor (3M Cache, 2.30 GHz)
Memory
Storage 1 x M.2 SATA SSD (Option : M.2 PCIe SSD and 2.5" HDD/SSD)
LCD Panel
True-Flat Projected Capacitive Multi Touch
Touch Panel
Speaker
I/O Expansion
4 x USB 3.0 and 2 x USB 2.0 type A (Bottom)
USB
LAN 1 x RJ45 10/100/1000Mbps Giga Ethernet
COM
LPT
VGA
HDMI
Audio
Cash Drawer 1 x RJ11 port supports 2 cash drawer with 12V or 24V by jumper
DC Power Out
DC Power In
Power Management
Power Adapter
Mechanical & Environment
Tilt Adjustment
Dimension
Weight
Certification
Operation System
Operation
0°C to +40°C / 20 to 80% without condensation (Equipped with HDD)
Condition
Storage Condition -20°C to +60°C / 20 to 85% without condensation
Optional Peripheral
8" (800 x 600), 9.7" (1024 x 768) and 10.1" (1280 x 800) LCD Display,
2nd Display
Customer Display
MSR Bi-directional, Comply with ISO 7811 and Three Track support
Barcode Scanner
Wi-Fi
VESA MOUNT Kit
POS-8717U
7th Generation Kaby Lake
2 x DDR4 SODIMM, up to 32GB
17-inch TFT LCD with LED Backlight
1280 (W) RGB x 1024(H)
True-Flat 5-wire Resistive Touch
1 x 2W High Quality Speaker
2 x USB 2.0 Type A (Panel Side)
3 x COM (RJ45), w/ RI/5V/12V
1 x COM (DB9), w/RI/5V/12V
1 x DB25 Parallel Port (Option)
1 x DB-15 VGA Port
1 x HDMI Port
1 x Line-out and 1 x MIC-in
1 x +12V Power Out
1 x Standard DIN 4PIN type
12V@7.5A 90W Adapter
15° ~ 85°
396 (W) x 381 (H) x 285 (D) mm
9 kg
CE/FCC/LVD/RCM
Windows 10 IoT
Option : PCAP Touch Panel
VFD and LCD Customer Display
CMOS Barcode Scanner
Wi-Fi IEEE 802.11 a/b/g/n/ac
VESA-Compatible, 75 x 75 (mm)
Full Flat 17-inch Touch Screen POS Terminal
Quick Installation Guide
POS-8717U
IMPORTANT SAFETY INFORMATION
 Read following instructions carefully.
 Use only parts, especially power adapter, recommended by the manufacturer;
unapproved parts may be hazardous.
 Make sure that the voltage applied to the power outlet is within the specified
range (100VAC ~240VAC).
Improper power source voltage range will cause damage.
 Power off the system and remove the power adapter while cleaning the system.
 Before powering on the system, make sure all the peripherals are
firmly installed.
