Main Board Layout

●
Main Board Connection / Installation Notes
The images below indicate the connectors and jumpers of the main board.
Each connector/slot is used for the specified part or optional peripheral.
Please refer to the notes as below and examine the layouts of the main boards to locate
the connectors so as to complete the installation.
i.e.:
To connect the HDD to the main board, please use the HDD cable and locate the
matched connector on the main board; then connect the HDD cable to the Hard Drive.
Connector/Slot
Memory Slot 1
SATA Connectors
USB
COMBO USB
PWR LED / PWR SW
LVDS Connector
eDP Connector*
Speaker (Audio Connector)
Connection/Installation Notes
Install the RAM module to the main board.
Please use the SATA HDD cable and connect to the
Hard drive.
Connect to the devices that support USB interface.
Connect to the optional MSR Module and the USB port
under the Main LCD Display.
Connect to Power Switch and LED Indicator
Use the LVDS Cable and connect to the LCD Panel.
The LCD Panel with eDP connector.
This is reserved for customized model only and not
available for standard model.
Connect the Speaker to the main board.
