Service Manual
POStation 7000 Series
Version 1.0
© Copyright Fametech Inc. (TYSSO) 2007
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POStation 7000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Fametech POStation 7000 Series

  • Page 1 Service Manual POStation 7000 Series Version 1.0 © Copyright Fametech Inc. (TYSSO) 2007 - 1 -...
  • Page 2 Table of Contents I. Part List.............................4 II. Flash/Update BIOS..........................8 III. System Disassembly........................10 - 2 -...
  • Page 3 Table of Figures Figure 1 Explode of the System ......................4 Figure 2 Cables ............................6 Figure 3 Mainboard Layout .........................7 - 3 -...
  • Page 4: I. Part List

    I Part List Figure 1 Explode of the System - 4 -...
  • Page 5 No. Part No. Description 1 JP-POS-6000-LCD-FRONT System Front Cover 2 KP-POS-7000-IBUTTON-READER I-Button Reader (Option) 3 KP-POS-7000-I-BUTTON I-Button (Option) 4 JP-POS-6000-BOTTOM-COVER Bottom Base Cover 5 JP-POS-MSR-SLOT-COVER MSR Cover 6 JP-POSMAL-KNOB On/Off Switch 7 BP-PART-POS-7000-I-BUTTON-PCBA I-Button Decorder Board 8 KP-POS-6000-MCR-HOLDER MSR Holder (Option) 9 JM-MCR-9-STAND-1H-B MSR Stand (Option) 10 RH-RMB-33-W7-NS-30-14...
  • Page 6: Figure 2 Cables

    Figure 2 Cables - 6 -...
  • Page 7: Figure 3 Mainboard Layout

    Figure 3 Mainboard Layout No. Part No. Description 1 CP-CBL-POS-7000-COM3&4 COM Port DB9 RS-232 Cable 2 CP-CBL-POS-7000-HDD HDD Cable 3 CP-CBL-POS-7000-INT Invertor Cable 4 CP-CBL-POS-7000-LED-HDD HDD LED Cable 5 CP-CBL-POS-7000-LED-PW Power LED Cable 6 CP-CBL-POS-7000-SW-B27cm Power Switch Cable 7 CP-CBL-POS-7000-MMSR KUR MSR Cable (Option) 8 CP-CBL-POS-7000-LVDS LVDS Cable...
  • Page 8: Ii. Flash/Update Bios

    II Flash/Update BIOS 1. Connected an external USB floppy or CD-ROM to POS-7000. Insert a DOS floppy or CD. Enter the DOS system. 2. As “A:\>” appears, enter “dir” and press the <Enter> key. The content of the floppy or CD will show on the screen.
  • Page 9 4. Enter “dir” and then press the <Enter> key. The content of the item to be updated will show on the screen. Enter “go” and the item will be flashed automatically. Do not turn off the computer or make any diaturbance in the process of flashing. 5.
  • Page 10: Iii. System Disassembly

    III System Disassembly 1. Remove the hinge swivel covers and loosen the screw x 6 on both sides. 2. Carefully take off the system from the aluminum base. Loosen the screw x 1 to remove the HDD cover and the screw x 5 to remove the hinge holder.
  • Page 11 4. Loosen the screw x 3 on the back of the mainboard cover. 5. Loosen the screw x 2 on both sides of the mainboard cover. 6. Loosen the screw x 6 on the mainboard cover. 7. Unplug the HDD and cooler connector. Remove the mainboard cover.
  • Page 12 8. Loosen the screw x 4 to remove the MSR (option). 9. Loosen the screw x 2 to remove the MSR stand (option). 10. Loosen the screw x 2 and disconnect the cables to remove the invertor. - 12 -...
  • Page 13 11. Loosen the screw x 2 to remove the touch control board. 12. Loosen the spacer x 12 and disconnect the DB9 cables to remove the I/O bracket. 13. Loosen the screw x 6 and disconnect the cable to remove the mainboard. 14.
  • Page 14 15. Turn over the mainboard and loosen the screw x 4 to remove the CPU gasket. 16. Remove the cooler. 17. Take off the CPU. - 14 -...
  • Page 15 18. Loosen the screw x 10 to remove the LCD panel holder. 19. Loosen the screw x 4 to remove the LCD panel. 20. Remove the touch panel rubber. - 15 -...
  • Page 16 - 16 -...
