Parts Description

No.
Item
1a
Front Bezel
1b
Power Indicator
Front Bezel
2a
(TYSSO Logo)
2b
Backlight LOGO Module
3
LCD Panel
4
Panel Chassis
5
IO Bracket
6
Speaker
7
Main Board
8
Power Switch Bracket
9
Power Switch
10
I/O Bracket
11a
Cooler Kit
11b
Bracket Mylar
11b-1 Bracket
12a
Rear Cover
12b
Rear Cover
13
Hard Disk Drive
14
HDD Cover
15
Antenna Plug
16
MSR/i-Button Unit
17
I/O Cover
Description
Capacitive Touch Front Bezel Set (Black)
Capacitive Touch Front Bezel Set (Silver)
Resistive Touch Front Bezel Set (Black)
Resistive Touch Front Bezel Set (Silver)
LED Power Indicator
Capacitive Touch Front Bezel Set-TYSSO LOGO (Black)
Capacitive Touch Front Bezel Set-TYSSO LOGO (Silver)
Resistive Touch Front Bezel Set-TYSSO LOGO (Black)
Resistive Touch Front Bezel Set-TYSSO LOGO (Silver)
TYSSO Backlight LOGO Module
15" LCD Panel
LCD Panel Chassis
IO Bracket (POS-6000-i)
IO Bracket (POS-6000-D2550)
IO Bracket (POS-6000-B)
Speaker
Main Board (POS-6000-i)
Main Board (POS-6000-D2550)
Main Board (POS-6000-B)
Main Power Switch Bracket
Main Power Switch
Side I/O Bracket
CPU COOLER (POS-6000-i only)
CPU Bracket Mylar
CPU Bracket
Metal Rear Cover (POS-6000-i)
Metal Rear Cover (POS-6000-D2550/POS-6000-B)
Hard Disk Drive (HDD 320GB/500GB or SSD 64 GB)
Metal HDD Cover
Antenna Plug (*)
MSR/i-Button Unit (**)
Side I/O Cover (when MSR not Installed) (**)
