KYMCO Downtown 350i Repair Manual page 422

8.Final Drive Downtown 350i
Install the transmission case cover onto the transmission. Fit the drive into its
bearing in the case and make sure it gear engages correctly with the
countershaft gear.
Turn the drive shaft and make sure the final shaft turns.
Insert the 9 transmission case cover bolts. Tighten the bolts to specification using
a 12 mm socket.
Torque
Thread
Item Qty
size (mm)
kgf-m lb-ft
Transmission case bolts 9 8 0.8-1.2 1.7-2.6
Install the rear wheel. See the Rear Wheel topic for more information.
Fill the final drive oil. See the Final Drive Oil topic for more information.
Install the CVT belt and pulleys. See the CVT Installation topic for more
information.
Install the belt case. See the Belt Case topic for more information.
8-16
