KYMCO MXU 300 Parts Manual

Hide thumbs Also See for MXU 300:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual , User Manual
AUG/13/05
車 KYMCO
車 KYMCO
車 KYMCO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MXU 300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KYMCO MXU 300

Summary of Contents for KYMCO MXU 300

  • Page 1 LA60AA(US): AUG/13/05 車 KYMCO 車 KYMCO 車 KYMCO...
  • Page 2 零 錄 零 參 LA60AA(US) 參 若 車不 車 (Sales mark) 零 參 車 零 漏 不吝 ABOUT THIS PARTS LIST This parts list is compiled all service parts for model LA60AA(US) Any difference between color chart and motorcycle will be revised according to motorcycle The sales mark 1.marking ** must add color code in the end before ordering parts When modification or additions to this parts list are made a revised edition at an appropriate time...
  • Page 3 CONTENTS ‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧1 ABOUT THIS PARTS LIST‧‧‧‧‧‧‧‧‧1 ‧‧‧‧‧‧‧‧‧‧‧‧ 5 LA60AA(US) COLOR CHART OF LA60AA(US)‧‧‧‧‧‧5 ‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧7 ‧‧‧‧‧‧‧‧ CONTENTS-ENGINE GROUP 車 ‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧9 CONTENTS-FRAME GROUP ‧‧‧‧‧‧‧‧ 9 零 ‧‧‧‧‧‧‧‧‧‧‧‧‧‧13 ENGINE PARTS LIST‧‧‧‧‧‧‧‧‧‧‧13 車 零 ‧‧‧‧‧‧‧‧‧‧‧‧‧‧59 FRAME PARTS LIST ‧‧‧‧‧‧‧‧‧‧‧ 59 零 索 ‧‧‧‧‧‧‧‧‧‧‧‧‧‧‧137 PART NO. INDEX‧‧‧‧‧‧‧‧‧‧‧‧‧137...
  • Page 4 53100-LCA5-900 STRIPE R FENDER FRONT 86523-LCA5-E61 STRIPE L FENDER FRONT 86533-LCA5-E61 STRIPE R SIDE COVER 86623-LDE9-E61 STRIPE L SIDE COVER 86633-LDE9-E61 STRIPE KYMCO 87532-LBE8-900 STRIPE K-LOGO 60MM 87532-LCA5-900 SEAR ASSY 77200-LCA5-E00 EMB K-LOGO 30MM 86102-LCA5-900 LABEL TIRE OFF ROAD 87505-LCA5-E00...
  • Page 5 (MODEL) LA60AA(US) COLOR CHART (PHOTO NO) NO.1 NO.2 NO.3 NO.4 NO.5 NO.6 綠 藍 (BASIC COLOR) (CODE) RR338SA NH001SA GG345SA YR159SA PB089SA YR160SA 零 零 數(VERSION) (PARTS NAME) (PARTS NO) Black Deep Green Blue Blue Yellow Ochre FR CARRIER LUGGAGE 77430-LCA5-E00 PIPE COMP FR BUMPER 85100-LCA5-E00...
  • Page 6 CONTENTS-ENGINE GROUP Cylinder Head Cover Cylinder Piston Crank Case -15- -21- -27- Cylinder Head Crankshaft Right Crankcase Cover Starting Motor -29- Drive Pulley -33- -37- Water Pump Generator Case Comp Mission -41- Transmission -47- Carburetor -53-...
  • Page 7 CONTENTS-FRAME GROUP Head Light -61- Speed Meter -63- Handle Steering -65- Master Cylinder -67- Fender Front -71- Stem Steering -73- Front Wheel -75- Rear Wheel -79- Seat -83-...
  • Page 8 CONTENTS-FRAME GROUP Battery Fuel Tank -85- -89- Fender Rear -91- Air Cleaner -93- Exhaust Muffler -97- Master Cylinder Rear -99- Cushion -105- Cushion Left Arm Swing -107- Rear Fork -109- Right Arm Swing -10-...
  • Page 9 CONTENTS-FRAME GROUP Side Case Rr Final Light Tail Harness Wire -111- -115- -117- Frame Body -121- Carrier Luggage -125- Radiator -127- Caution Label -133- Emblem Stripe -135- -11-...
  • Page 10 Crank Case -14-...
  • Page 11 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 11100-LDE9-E00 CRANK CASE COMP R 11192-LBA7-900 GASKET CRANK CASE @A 11200-LCD9-E00 CRANK CASE COMP L 11341-LBA7-900 COVER LEFT 11348-LCA5-E00 COVER STARTING 11395-LBA7-900 GASKET L COVER 拉...
  • Page 12 Crank Case -16-...
  • Page 13 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 螺 90001-GFY6-901 SOCKET BOLT 6*10 螺 90031-KEBE-900 BOLT A STUD 8MM 螺 90031-KKA7-900 BOLT B STUD 8MM 拉 9008A-LCA5-E00 COVER ASSY HOLDER 90133-LLB1-900 WASHER BOLT SEAT 90441-KDY4-901 PLATE BRG HOLD 90441-LBA7-900...
  • Page 14 Crank Case -18-...
  • Page 15 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 94101-LCA5-E00 WASHER PLAIN 6MM 94301-08140 DOWEL PIN 8*14 94301-10160 DOWEL PIN 10*16 94591-LLB1-900 CLIP 2*100 螺 95701-08012-08 BOLT FLANGE 8*12 螺 96001-06010-08 BOLT FLANGE SH 6*10 螺...
  • Page 16 Cylinder Head Cover Cylinder Head -20-...
  • Page 17 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 12200-LDE9-900 HEAD COMP CYLN 螺 12205-KHE8-301 BOLT SEALING 12MM 12209-GDB4-68A SEAL VALVE STEM 輪 1221A-LDB2-E00 HOLDER COMP CAM SHAFT 12251-KHE7-901 GASKET CYLINDER HEAD 12310-LDB2-E00 COVER COMP CYLN HEAD 12391-LDB2-E00 GASKET HEAD COVER 輪...
  • Page 18 Cylinder Head Cover Cylinder Head -22-...
  • Page 19 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 18646-GFY6-941 GASKET A/I PIPE 19300-KAE1-004 THERMOSTAT ASSY 19310-KHE7-900 CASE COMP THERMOSTAT 19315-LBA7-900 COVER THERMOSTAT 37720-KGB5-900 EARTH TERMINAL THERMO 37750-PAC1-005 THERMO UNIT ASSY 螺 90012-3C33-001 SCREW TAPPET ADJUSTING 螺...
  • Page 20 Cylinder Head Cover Cylinder Head -24-...
  • Page 21 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 94591-KFBF-900 CLIP 2*71 螺 95701-06025-08 BOLT FLANGE 6*25 螺 96001-06018-08 BOLT FLANGE SH 6*18 螺 96001-06110-08 BOLT FLANGE SH 6*110 塞 98069-5791R-00 SPARK PLUG DPR (7EA-9) -25-...
  • Page 22 Cylinder Piston Crankshaft -26-...
  • Page 23 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 12100-LDE9-E00 CYLINDER COMP 12191-KHE7-900 GASKET CYLINDER 13000-LDE9-E00 CRANK SHAFT COMP 塞 13011-KHE7-900 RING SET PISTON 塞 13101-LDB2-E00 PISTON 塞 13111-LDB2-E00 PIN PISTON 1342A-LDE9-E00 SHAFT COMP BALANCER 輪...
  • Page 24 Right Crankcase Cover Water Pump -28-...
  • Page 25 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 11330-LDE9-E00 COVER COMP R CRANK CASE 11394-LBA7-900 GASKET R COVER 螺 12361-GFY6-901 HOLE CAP TAPPET ADJUSTING 濾 15421-1G07-001 SCREEN OIL FILTER 濾 15426-GAE1-921 SPG OIL FILTER SCREEN 量...
  • Page 26 Right Crankcase Cover Water Pump -30-...
  • Page 27 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 91302-KHE7-900 O RING 27.4*2.1 91303-3G77-001 O-RING 13.8*2.5 91307-0E35-001 O-RING 18*3 94301-08140 DOWEL PIN 8*14 94301-10160 DOWEL PIN 10*16 94520-26000 CIR CLIP IN 26 95002-KHE7-900 CLIP WATER HOSE 螺...
  • Page 28 E 5 Drive Pulley -32-...
  • Page 29 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 11347-LBA7-900 BOSS DRIVE SHAFT 離 22101-LBA7-900 OUTER CLUTCH 葉 22102-KHE7-900 FACE DRIVE 22105-LBA7-900 BOSS DRIVE FACE 滑 22110-KHE7-900 FACE COMP MOVABLE DRIVE 22112-KHE7-900 BUSH 27*33*37 22121-LBA7-900 ROLLER COMP WEIGHT 22131-LBA7-900...
  • Page 30 E 5 Drive Pulley -34-...
  • Page 31 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 23226-GHC8-004 ROLLER GUIDE 23233-LBA7-900 SPG DRIVEN FACE 23237-KHE7-900 COLLAR SEAL 23238-KHE7-900 COLLAR SPG 28213-LCA5-E00 PLATE RACHET 螺 90201-KHE7-900 NUT C FLANGE M12 螺 90201-KHR8-75A NUT FLANGE 14MM 螺...
  • Page 32 Starting Motor Generator -36-...
  • Page 33 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 15100-LBA7-900 PUMP ASSY OIL 輪 15133-KAM1-001 SPROCKET OIL PUMP DRIVE 15141-LBA2-E00 CHAIN OIL PUMP 15711-KHE7-900 SEPARATER OIL 輪 28101-KHE7-900 GEAR STARTER REDUCTION 輪 28102-LDE9-E00 SHAFT STARTER REDUCTION 輪...
  • Page 34 Starting Motor Generator -38-...
  • Page 35 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 螺 93500-05016-0H SCREW PAN 5*16 螺 94303-04065 PIN DOWEL 4*6.5 94510-10000 CIR CLIP EX 10 螺 96001-06012-08 BOLT FLANGE SH 6*12 螺 96001-06028-08 BOLT FLANGE SH 6*28 螺...
  • Page 36 E 7 Case Comp Mission -40-...
  • Page 37 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 11221-LBA7-900 TUBE MISSION BREATHER 輪 12431-LCD9-E00 GEAR TACHOMETER 21200-LCD9-E00 CASE COMP MISSION 21202-LCD9-E00 CAP MISSION 21203-LCD9-E00 CASE FINAL SHAFT 21395-LCD9-E00 GASKET MISSION CASE 力 21396-LCD9-E00 GASKET MISSION COVER 23431-LCD9-E00 SHAFT FINAL...
  • Page 38 E 7 Case Comp Mission -42-...
  • Page 39 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 輪 90317-LCD9-E00 SHIM DRIVE BEVEL GEAR G 輪 90318-LCD9-E00 SHIM DRIVE BEVEL GEAR H 輪 90319-LCD9-E00 SHIM DRIVE BEVEL GEAR I 輪 90320-LCD9-E00 SHIM DRIVE BEVEL GEAR J 輪...
  • Page 40 E 7 Case Comp Mission -44-...
  • Page 41 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 94520-58000 CIR CLIP IN 58 95002-02150 CLIP B15 TUBE 螺 95701-08012-08 BOLT FLANGE 8*12 螺 95701-08035-08 BOLT FLANGE 8*35 螺 95701-08040-08 BOLT FLANGE 8*40 螺 96001-06020-08 BOLT FLANGE SH 6*20 96100-60090-00...
  • Page 42 E 8 Transmission -46-...
  • Page 43 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 23211-LCD9-E00 SHAFT MAIN 23411-LCD9-E00 SHAFT DRIVE 23421-LCD9-E00 SHAFT COUNTER 輪 23422-LCD9-E00 GEAR COUNTER 輪 23440-LCD9-E00 GEAR ASSY FORWARD 車 輪 23451-LCD9-E00 GEAR BACKWARD 車 23471-LCD9-E00 SHIFT REVERSE &...
  • Page 44 Transmission -48-...
  • Page 45 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 輪 24701-LCD9-E00 GEAR CHANGE HNDL 螺 90001-GFY6-901 SOCKET BOLT 6*10 輪 90331-LCD9-E00 SHIM DRIVEN BEVEL GEAR A 輪 90332-LCD9-E00 SHIM DRIVEN BEVEL GEAR B 輪 90333-LCD9-E00 SHIM DRIVEN BEVEL GEAR C 輪...
  • Page 46 Transmission -50-...
  • Page 47 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 90452-LBA7-900 WASHER THRUST 25MM 90455-LBA7-900 WASHER SPLINE 25MM 90455-LDE9-E00 WASHER SPLINE 20MM 90474-3C33-001 WASHER 8MM 90521-0H28-001 DIA WASHER 17*22 90605-KED9-900 SET RING 28MM 91106-LBA7-900 BRG NEEDLE 20*26*16 91106-LBA7-90A BRG NEEDLE 20*26*16 螺...
  • Page 48 Carburetor -52-...
  • Page 49 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 001-C4T2-04000 COMPR SPG 1010-43FH-9900 NEEDLE JET 1012-382H-0140 JET HOLDER 螺 1014-840-2000 ADJUST SCREW 流 塞 1020-54D0-9900 THROTTLE VALVE 流 塞 1031-KN4H-6511 TOP GASKET 流 塞 103J-061H-9901 TOP COMP 1051-KCSH-9200...
  • Page 50 Carburetor -54-...
  • Page 51 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 16119-MZ2-6000-K2 STAY PLATE 16155-ZG8-L100 FLOAT VALVE COMP 流 螺 16162-KG8-9010-M1 DRAIN SCREW 1782-013H-9900 SPECIAL CLIP 1785-KG40-0030 TUBE 1795-KG8H-9010 PLAIN WASHER 螺 93892-04008-18 WASHER SCREW 螺 93892-04010-18 WASHER SCREW 螺...
  • Page 52 Carburetor -56-...
  • Page 53 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price W9535-25000 TUBE CLIP W9535-35000 CLIP W9574-13000 NEEDLE CLIP PLATE 螺 W9576-01000 STOP SCREW -57-...
  • Page 54 Head Light -60-...
  • Page 55 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 33100-LCA5-E00 LIGHT ASSY R HEAD 33110-LCA5-E00 UNIT HEAD LIGHT R 33120-LCA5-E00 UNIT HEAD LIGHT L 33130-LCA5-E00 SOCKET COMP 33150-LCA5-E00 LIGHT ASSY L HEAD 34901-KFA6-900 BULB HEAD LIGHT 34903-KPCP-900 BULB POSITION LIGHT 90651-LCA5-E00...
  • Page 56 Speed Meter -62-...
  • Page 57 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 37200-LCD9-90A METER ASSY SPDMT 44830-LBA7-E00 CABLE COMP SPDMT 44831-KFA6-900 CABLE INNER 螺 93903-35260 SCREW TAPPING 5*12 -63-...
  • Page 58 Handle Steering -64-...
  • Page 59 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 流 17910-LBA7-900 CABLE COMP THROT 17950-LCA5-E00 CABLE COMP CHOKE 32161-4D04-001 BAND WIRE HARNESS B1 3520A-LCD9-900 SW ASSY LH HANDLE COMP 53100-LCA5-900 HANDLE PIPE STRG 53102-LBA7-900 STAY HANDLE COVER 流拉...
  • Page 60 Master Cylinder -66-...
  • Page 61 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 車 35340-LBA7-900 SW ASSY FR STOP 車 35350-KNBN-901 SW ASSY RR STOP 車 43125-LCD9-E00 HOSE COMP RR BRK 車 43127-LCD9-E00 HOSE COMP RR BRK 車 43128-LBA7-900 CLAMPER RR BRAKE HOSE 車...
  • Page 62 Master Cylinder -68-...
  • Page 63 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 拉 螺 90114-1F66-007 BOLT HANDLE LEVER 螺 90145-MKS9-61A-06 OIL BOLT 10*22 90545-3L00-001 WASHER OIL BOLT 螺 93600-04012-1A SCREW FLAT 4*12 螺 93600-04012-1G SCREW FLAT 4*12 螺...
  • Page 64 Fender Front -70-...
  • Page 65 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 17700-LCA5-E00 COVER TANK 流 17705-LCA5-E00 TUBE ASSY FUEL DRAIN 17720-LBA7-900 TRAY TANK COVER 泥 60100-LCA5-E00 FENDER FRONT 60120-LCD9-E00 GUIDE COVER CHANGE HANDLE 64301-LCA5-E00 COVER FRONT 64302-LCA5-E00 BUMPER FRONT 泥...
  • Page 66 Stem Steering -72-...
  • Page 67 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 53200-LBA7-900 STEM COMP STEERING 53250-LBA7-900 COLLAR STEM BOTTOM 53251-LCA5-E00 HOLDER STEM STEERING 53252-LBA7-900 CLAMPER STEM HOLDER 53254-LBA7-900 SLEEVE STEM 連 53700-LCA5-E00 ROD ASSY STEERING 連 53701-LCA5-E00 ROD COMP STEERING 53702-LLB1-900...
  • Page 68 Front Wheel -74-...
  • Page 69 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 42753-KNBN-90B VALVE RIM (TR 412) 輪 44311-LBA7-900 COLLAR FR WHEEL SIDE A 輪 44312-LBA7-900 COLLAR FR WHEEL SIDE B 輪 44313-LBA7-900 COLLAR FR WHEEL DIST 輪...
  • Page 70 Front Wheel -76-...
  • Page 71 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 車 45210-LBA7-305 BRACKET L 45230-LBA7-900 BUSH PIN 螺 45232-LBA7-900 PIN BOLT 45352-LBA7-900 BLEEDER 45353-LBA7-900 CAP BLEEDER 塞 45531-LBA7-900 PLUG 輪 47410-LCA5-E00 CAP WHEEL SHAFT 螺 90105-LBA7-900 BOLT CONNECTOR 螺...
  • Page 72 Rear Wheel -78-...
  • Page 73 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 輪 42705-LCA5-E00 RIM RR WHEEL 輪 連 4270A-LCA5-E00 HUB ASSY RR WHEEL 輪 42710-LCA5-E0A TIRE ASSY RR 輪 42710-LCA5-E0B TIRE ASSY RR 42753-KNBN-90B VALVE RIM (TR412) 車...
  • Page 74 Rear Wheel -80-...
  • Page 75 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 塞 45531-LBA7-900 PLUG 輪 47410-LCA5-E00 CAP WHEEL SHAFT 連 螺 90105-LBA7-900 BOLT CONNECTOR 螺 90105-MLL0-731 BOLT RR DISK 8*24 輪 螺 90301-LBA7-900 NUT WHEEL 螺 94011-LBA7-900 NUT FLANGE CASTLE 16MM 94201-30300...
  • Page 76 Seat -82-...
  • Page 77 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 77200-LCA5-E00 SEAT ASSY 77303-LLB1-900 HOOK ASSY SEAT LOCK 89010-LBA7-900 TOOL SET 89020-KKC4-900 BAND TOOL SET -83-...
  • Page 78 Fuel Tank -84-...
  • Page 79 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 濾 1691A-GFY6-90A STRAINER ASSY FUEL 16950-LBA7-900 COCK FUEL 16951-LBA7-900 COVER FUEL COCK 濾 16952-LLB1-900 SCREEN FUEL STRAINER 17500-LCA5-E01 TANK COMP FUEL 17522-LLB1-900 RUBBER FUEL TANK 17524-LLB1-900 RR RUBBER FUEL TANK 1760A-LBA7-900...
  • Page 80 Fuel Tank -86-...
  • Page 81 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 9500E-LBA7-900 TUBE ASSY FUEL 螺 95701-06022-06 BOLT FLANGE 6*22 -87-...
  • Page 82 Battery -88-...
  • Page 83 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 31500-KHE7-90A BATTERY YTX12-BS 31500-KHE7-90B BATTERY GTX12-BS 50328-LCA5-E00 BAND BATTERY 80300-LCA5-E00 COVER BATTERY 螺 90302-LLB1-E00-06 BOLT-WASH 5*12 -89-...
  • Page 84 Tank Cover Luggage Box -90-...
  • Page 85 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 64222-LLJ3-E00 RUBBER WIND SCREEN 泥 80100-LCA5-E00 FENDER REAR 泥 80110-LBA7-900 RUBBER REAR FENDER 80121-LCA5-E00 MUDGUARD R FLOOR 80122-LCA5-E00 MUDGUARD L FLOOR 80125-LBD4-900 COLLAR FLOOR 泥 80200-LCA5-E00 MOLDING RR FENDER 83500-LCA5-E00...
  • Page 86 Air Cleaner -92-...
  • Page 87 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 濾 17214-LBA7-900 SEAL AIR/C COVER 濾 濾 1721A-LBA7-900 ELEMENT COMP AIR/C 濾 17231-LBA7-900 COVER AIR/C 17237-KED9-900 OIL CATCH ASSY 濾 1723A-LDE9-E00 CASE ASSY AIR/C 濾 17246-LBA7-900 CLAMP AIR/C 連...
  • Page 88 Air Cleaner -94-...
  • Page 89 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 95002-KKD6-E05 CLAMP D18 TUBE 95003-LBA7-900 TUBE DRAIN 螺 95701-06012-06 BOLT FLANGE 6*12 -95-...
  • Page 90 Exhaust Muffler -96-...
  • Page 91 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 18291-LBA7-900 GASKET EXH PIPE 18293-LBA7-E00 RUBBER MUFFLER STAY 18294-KTCT-900 PACKING PROTECTOR 18294-LBA7-E00 PACKING MUFFLER STAY 1830A-LDE9-800 MUFFLER ASSY EXH 18325-LLB1-900 PROTECTOR PIPE EXHAUST 18424-LBA7-E00 COLLAR MUFFLER STAY 螺...
  • Page 92 Master Cylinder Rear -98-...
  • Page 93 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 連 24700-LCD9-E00 GEAR CHANGE HNDL LINK 24702-PWA1-900 BAR CHANGE HNDL 24703-LLB1-900 PIN CHANGE HNDL 24704-LBA7-900 SPRING CHANGE HNDL 24707-LBA7-900 BRKT CHANGE HNDL 24710-PWA1-900 STAY CHANGE HNDL ASSY 24711-PWA1-900 SHAFT COMP CHANGE HNDL 連...
  • Page 94 Master Cylinder Rear -100-...
  • Page 95 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 車 46513-KED9-900 SPG SET BRK PEDAL 連 53702-LBA7-900 JOINT R BALL 連 53703-LBA7-900 JOINT L BALL 螺 90101-LCA5-E00-06 SOCKET BOLT 5*12 90501-3L10-001 WASHER 7*12 螺 93600-04040-1G SCREW FLAT 4*40 螺...
  • Page 96 Master Cylinder Rear -102-...
  • Page 97 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 螺 95701-08028-06 BOLT FLANGE 8*28 螺 96001-06014-07 BOLT FLANGE SH 6*14 -103-...
  • Page 98 Cushion Right Arm Swing -104-...
  • Page 99 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 44620-PWA2-900 COLLAR SWING ARM 45140-LCA5-E00 GUARD BRAKE DISK 47400-LCA5-E00 KNUCKLE ASSY R STEERING 51400-PWA1-900 CUSHION ASSY FR 53400-PWA2-900 ARM ASSY R UP SWING 53450-LCD9-E00 ARM ASSY R LOW SWING 螺...
  • Page 100 Cushion Left Arm Swing -106-...
  • Page 101 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 44620-PWA2-900 COLLAR SWING ARM 45140-LCA5-E00 GUARD BRAKE DISK 47500-LCA5-E00 KNUCKLE ASSY L STEERING 51400-PWA1-900 CUSHION ASSY FR 53500-PWA2-900 ARM ASSY LEFT UP SWING 53550-LCD9-E00 ARM ASSY LEFT LOW SWING 螺...
  • Page 102 Rear Fork -108-...
  • Page 103 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 40540-LCD9-E00 PLATE ASSY SKID 輪 42302-LDE9-E00 AXLE RR WHEEL 52000-LDE9-900 FORK ASSY RR 52111-LDE9-E00 HOLDER GREASE 52130-LDE9-E00 STOPPER ASSY RR 52400-PWA1-900 CUSHION ASSY RR 螺 90121-LCD9-E00 FORK PIVOT BOLT RH 螺...
  • Page 104 Side Case Rr Final -110-...
  • Page 105 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 螺 12361-GFY6-901 HOLE CAP TAPPET ADJUSTING 輪 41310-LCD9-E00 L SIDE CASE RR FINAL 輪 41320-LCD9-E00 R SIDE CASE RR FINAL 41405-LCD9-E00 RING STOPPER 輪 41421-LCD9-E00 GEAR PINION 輪...
  • Page 106 Side Case Rr Final -112-...
  • Page 107 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 91271-LCD9-E00 OIL SEAL 42*62*7 91301-LCD9-E00 O-RING 74.4*3.1 91302-0A01-021 O-RING 30.8MM 91303-LCD9-E00 O-RING 31.7*3.5 95002-41050-00 CLIP D10.5 TUBE 95005-LCD9-E00 BREATHER TUBE RR GEAR ASSY 螺 95701-08012-08 BOLT FLANGE 8*12 螺...
  • Page 108 F20 Light Tail -114-...
  • Page 109 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 33700-LCA5-900 LIGHT ASSY R RR COMB 33701-LCA5-900 UNIT TAIL LIGHT R 33710-LCA5-900 SOCKET COMP RR COMB 33740-LCA5-E00 REFLECTOR ASSY R RR 33745-LCA5-E00 REFLECTOR ASSY L RR 33750-LCA5-900 LIGHT ASSY L RR COMB 33751-LCA5-900...
  • Page 110 F21 Harness Wire -116-...
  • Page 111 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 30400-LDE9-E00 UNIT ASSY IGNITION 3051A-KHE7-900 COIL ASSY IGNITION 塞 30700-KFC8-E0H CAP ASSY NOISE SUPPRESOR 流 31600-LBA7-900 REG REC COMP 32100-LCD9-900 HARNESS WIRE 32101-LLB1-800 SUB CORD 32161-LBA7-900 BAND WIRE 32411-LCA5-E00...
  • Page 112 F21 Harness Wire -118-...
  • Page 113 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 38200-KEBE-900 BOX COMP FUSE 3860A-LCA5-E01 CONTROL UNIT LIGHTIN 輪 3900A-LBA7-900 CONTROL ASSY GEAR CHANGE 螺 90164-0H28-900 SCREW FLAT U LOCK 6*12 螺 94050-06080 NUT FLANGE 6MM 螺...
  • Page 114 Frame Body -120-...
  • Page 115 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 車 50100-LCD9-900 BODY COMP FRAME 50166-LBA7-900 STAY START MAG SW 50172-LBA7-900 STAY CATCH TANK 50188-LCD9-E00 STAY STOP SW 50219-LCA5-E00 STAY WINKER RELAY 50351-LBA7-900 BRKT ENG HANGER 51406-LCA5-E00 RH STAY FR CARRIER 51407-LCA5-E00...
  • Page 116 Frame Body -122-...
  • Page 117 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 螺 95801-10160-06 BOLT FLANGE 10*160 螺 95801-10085-06 BOLT FLANGE 10*85 96150-62030-10 BEARING BALL RADIAL 6203 -123-...
  • Page 118 F23 Carrier Luggage -124-...
  • Page 119 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 50614-LCA5-E00 STAY R FLOOR PANEL 50615-LCA5-E00 STAY L FLOOR PANEL 77330-LCA5-E00 REAR CARRIER LUGGAGE 77430-LCA5-E00 FRONT CARRIER LUGGAGE 85100-LCA5-E00 PIPE COMP FR BUMPER 85101-LCA5-E00 CAP PIPE 螺...
  • Page 120 Radiator -126-...
  • Page 121 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 11344-LCA5-E00 DUCT B L COVER 11345-LCA5-E00 DUCT A L COVER 11346-GFY6-901 BAND L COVER DUCT 11346-KKC3-900 BAND L COVER DUCT 11346-LCA5-E00 DUCT C L COVER 濾...
  • Page 122 Radiator -128-...
  • Page 123 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 19111-GBE2-004 CAP COMP 19210-KKC4-900 CAP RESERVE TANK 19504-LBA7-900 HOSE WATER D RADIATOR-ENG 19505-LBA7-900 HOSE WATER F ENG-RADIATOR 19506-LBA7-900 HOSE WATER G RADIATOR-PRESSURE VALVE 37760-KHD8-900 SW ASSY THERMO 64317-LBA7-900 STAY RADIATOR UP 64318-LBA7-900...
  • Page 124 Radiator -130-...
  • Page 125 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 95002-KHE7-900 CLIP WATER HOSE 95002-KGN7-910 CLIP TUBE 螺 95701-06012-06 BOLT FLANGE 6*12 -131-...
  • Page 126 Caution Label -132-...
  • Page 127 零 數 量 Sales mark Ref no Part no Description Chinese Regd no Ref Price 87322-LBA7-E00 CAUTION SHIFIT GEARS 87505-LCA5-E00 LABEL TIRE OFF ROAD 87514-LDE9-E00 CAUTION MAXIMUM CAPACITY 87515-LBA7-E00 CAUTION LIST 87517-LBA7-E00 CAUTION DRIVE AGE 87556-LCA5-E00 CAUTION CARRIER MAX LOAD (30KG) 87556-LLB1-E01 CAUTION CARRIER MAX LOAD 87560-LBA7-E00...
  • Page 128 Emblem Stripe -134-...
  • Page 129 Part no Description Chinese Regd no Ref Price 86102-LCA5-900 STRIPE K-LOGO 30MM 86523-LCA5-E61 STRIPE R FR FENDER 86533-LCA5-E61 STRIPE L FR FENDER 86623-LDE9-E61 STRIPE R RR FENDER 86633-LDE9-E61 STRIPE L RR FENDER 87532-LBE8-900 STRIPE KYMCO 87532-LCA5-900 STRIPE K-LOGO 60MM -135-...
  • Page 130 零 索 PART NO. INDEX 零 數 零 數 零 數 PART NO. VERSION PAGE PART NO. VERSION PAGE PART NO. VERSION PAGE 11395-LBA7-900 P-15 1300-KG8H-Q010 P-53 11700-LCA5-E00 P-15 13011-KHE7-900 P-27 001-C4T2-04000 P-53 11701-LCA5-E00 P-15 1305-491H-9901 P-53 11702-LCA5-E00 P-15 13101-LDB2-E00 P-27 11703-LCA5-E00 P-15...
  • Page 131 零 索 PART NO. INDEX 零 數 零 數 零 數 PART NO. VERSION PAGE PART NO. VERSION PAGE PART NO. VERSION PAGE 15421-1G07-001 P-29 17255-KKAK-900 P-127 15426-GAE1-921 P-29 17257-LBA7-900 P-93 15441-1K49-001 P-27 17265-LBA7-900 P-93 19000 15447-1K49-001 P-27 17369-KDB4-671 P-93 1565A-KKAK-900 P-29 17369-KHC4-900...
  • Page 132 零 索 PART NO. INDEX 零 數 零 數 零 數 PART NO. VERSION PAGE PART NO. VERSION PAGE PART NO. VERSION PAGE 21200-LCD9-E00 P-41 23237-KHE7-900 P-35 24721-LCD9-E00 P-99 21202-LCD9-E00 P-41 23238-KHE7-900 P-35 24781-LCA5-E00 P-99 21203-LCD9-E00 P-41 23411-LCD9-E00 P-47 21395-LCD9-E00 P-41 23421-LCD9-E00 P-47...
  • Page 133 零 索 PART NO. INDEX 零 數 零 數 零 數 PART NO. VERSION PAGE PART NO. VERSION PAGE PART NO. VERSION PAGE 32161-LBA7-900 P-117 35100-LCA5-305-M1 P-117 3900A-LBA7-900 P-119 32410-LBA7-900 P-37 35100-LCA5-305-M2 P-117 32411-LCA5-E00 P-117 35111-LCA5-325-M1 P-117 32412-LCA5-E00 P-37 35111-LCA5-325-M2 P-117 40000 32976-1G07-001...
  • Page 134 零 索 PART NO. INDEX 零 數 零 數 零 數 PART NO. VERSION PAGE PART NO. VERSION PAGE PART NO. VERSION PAGE 42710-LCA5-E0B P-79 45232-LBA7-900 P-79 42753-KNBN-90B P-75 45000 45352-LBA7-900 P-77 42753-KNBN-90B P-79 45352-LBA7-900 P-79 45100-LBA7-900 P-75 45353-LBA7-900 P-77 45105-LBA7-305 P-75 45353-LBA7-900...
  • Page 135 零 索 PART NO. INDEX 零 數 零 數 零 數 PART NO. VERSION PAGE PART NO. VERSION PAGE PART NO. VERSION PAGE 50166-LBA7-900 P-121 53175-LBA7-900 P-67 64302-LCA5-E00 P-71 50172-LBA7-900 P-121 53178-KFC8-E10 P-67 64303-LCA5-E00 P-71 50188-LCD9-E00 P-121 53200-LBA7-900 P-73 64304-LCA5-E00 P-71 50219-LCA5-E00 P-121...
  • Page 136 零 索 PART NO. INDEX 零 數 零 數 零 數 PART NO. VERSION PAGE PART NO. VERSION PAGE PART NO. VERSION PAGE 90123-LCD9-E00 P-109 90133-LLB1-900 P-17 84000 89000 90145-MKS9-61A-06 P-69 90164-0H28-900 P-119 84703-LLB1-900 P-121 89010-LBA7-900 P-83 90201-KHE7-900 P-35 89020-KKC4-900 P-83 90201-KHR8-75A P-35...
  • Page 137 零 索 PART NO. INDEX 零 數 零 數 零 數 PART NO. VERSION PAGE PART NO. VERSION PAGE PART NO. VERSION PAGE 90320-LCD9-E00 P-43 90501-3L10-001 P-101 91201-KKJ9-004 P-29 90321-LCD9-E00 P-43 90521-0H28-001 P-51 91202-KKC4-900 P-17 90322-LCD9-E00 P-43 9052A-GFY6-950 P-17 91202-LLB1-900 P-121 90331-LCD9-E00 P-49...
  • Page 138 零 索 PART NO. INDEX 零 數 零 數 零 數 PART NO. VERSION PAGE PART NO. VERSION PAGE PART NO. VERSION PAGE 93903-34360 P-71 94050-06080 P-121 93903-34360 P-91 94050-08080 P-23 92000 93903-35260 P-61 94050-08080 P-97 93903-35260 P-63 94050-08080 P-101 92101-05032-0H P-37 93903-35260...
  • Page 139 零 索 PART NO. INDEX 零 數 零 數 零 數 PART NO. VERSION PAGE PART NO. VERSION PAGE PART NO. VERSION PAGE 94510-25000 P-51 9500E-LBA7-900 P-87 95801-10057-06 P-105 94520-26000 P-31 95701-06010-06 P-69 95801-10057-06 P-107 94520-28000 P-35 95701-06010-06 P-105 95801-10085-06 P-123 94520-40000 P-121...
  • Page 140 零 索 PART NO. INDEX 零 數 零 數 零 數 PART NO. VERSION PAGE PART NO. VERSION PAGE PART NO. VERSION PAGE 96100-63030-00 P-51 96100-63040-00 P-19 96150-60000-10 P-105 96150-60000-10 P-107 96150-60040-10 P-77 N413-15A00 P-55 96150-60060-10 P-109 N427-BSD00 P-55 96150-62020-10 P-77 96150-62030-10 P-123...
