2.2 Parts and function
Figure 2-2:
1 Field connection indicator light
2 Power indicator light
3 USB port
4 Fieldbus device connection socket
(*) See the Indicator light scenarios table.
USB Fieldbus Interface
(*)
(*)
Indicates the fieldbus device connection status
Indicates the power mode of the interface
Enables USB connection
Enables fieldbus device or segment connection
