Emerson USB Fieldbus Interface User Manual page 30

User's Manual
• Manually entering IP addresses displays manually entered FF HSE
networks and the USB Fieldbus Interface in the AMS Device Manager
hierarchy.
• The USB Fieldbus Interface does not support FF device alerts.
7. Click Finish.
5.2 Configure fieldbus devices in AMS Device Manager
Note
Commission fieldbus devices first in the USB Fieldbus Interface Configuration
utility before configuring them in AMS Device Manager. For more
information, see
1. Click Start > All Programs > AMS Device Manager > AMS Device Manager to open
AMS Device Manager.
2. From the Device Connection or Device Explorer view, right-click the FF
HSE network icon and select Rebuild Hierarchy.
The USB Fieldbus Interface icon then appears under the FF HSE network.
Figure 5-5:
30
Section 4.4.
USB Fieldbus Interface icon in AMS Device Manager
January 2019
