INSTRUMENT CONNECTION

The instrument supply leads should not be in proximity of the incoming low-potential signals.
Contactors, motors with larger input power should not be in proximity of the instrument.
The leads into the instrument input (measured quantity) should be in sufficient distance from all power leads and appliances.
Provided this cannot be secured it is necessary to use shielded leads with connection to ground (bracket E).
The instruments are tested in compliance with standards for use in industrial area, yet we recommend to abide by the above
mentioned principles.

MEASURING RANGES

Type Input I
0...60/150/300/1 200 mV
DC
0...5/20 mA/4...20 mA
PM
OHM 0...0,1/1/10/100 kΪ
RTD-Pt Pt 100/Pt 500/ Pt 1 000
RTD-Ni Ni 1 000/10 000
T/C J/K/T/E/B/S/R/N
DU Linear potentiometer (min. 500 Ϊ)
OPTION "A"
Type Input I
DC 0...1 A/0...5 A
OPTION "B"
Type Input 2, 3, 4/I
0...5/20 mA/4...20 mA
PM
|
6 INSTRUCTIONS FOR USE OM 402UNI
Input U
±2/±5/±10/±40 V
Input U
±120 V/±250 V/±500 V
Input 2, 3, 4/U
±2/±5/±10/±40 V
