Peripheral Devices

With the exception of the Customer Displays and Cash Drawers, the peripheral
devices listed below are connected to the Workstation through a RS232 interface.
• 10–Inch Customer Display
•

Customer Display

• Cash Drawer
• Barcode Reader
• Coin Changer
• Magnetic Card Reader
• Scale
• Order Confirmation and Payment Terminal
10–Inch Customer Display
The 10–Inch Customer Display shows transaction totals and status. When a check is
paid, the display shows the amount tendered and any change due. The 10–Inch
Customer Display is compatible with the Oracle MICROS Workstation 6 Series.
Both high-mount and pole displays are available.
Table 18-1
Feature
Display Resolution
Aspect Ratio
Viewing Angle
Input Voltage
Assembled Dimensions and Weight 10-Inch Customer Display with Pole Mount: 22 x 10.02 x
Temperature and Humidity
Customer Display
The customer display shows transaction totals and status. When a check is paid, the
display shows the amount tendered and any change due.
Both integrated and pole displays are available.
Technical Specifications for the 10–Inch Customer Display

10-Inch Customer Display

Up to 1280 x 800 @ 60Hz
16:10
Horizontal: ±85° or 170° total / Vertical: ±85° or 170° total
12VDC +/- 5%; 100-240VAC, 50/60Hz
3.65 in/ 558.8 x 254.5 x 92.71 mm; 3.63 lbs/ 1.65 kg
10-Inch Customer Display with High-Mount: Up to 14.25 x
15.5 x 16 in/ 361.95 x 393.7 x 406.4 mm; adds ~1.75 lbs/
0.79 kg to workstation/stand weight
Operation: 0°C to 40°C / 32°F to 104°F; Humidity: 20% to
80%
