Table 6-1 (Cont.) MICROS Tablet R-Series Features
Feature
Display
Operating System
Touchscreen
Memory
Storage
Backlight
Case Material
Weight
Physical Dimensions
Mag Stripe Reader
Ports
Network
Battery
Input Power
BTU/Hour
Operating Temperature
Storage Temperature
Certifications
MICROS Tablet R-Series Features
Specifications
10.1" WVGA (1024x600) TFT LCD /w LED
Backlights Portrait or Landscape orientation
and Auto-Rotation
Two LCD options are available:
• Standard 10.1" LED backlit TFT LCD
• Daylight readable TFT based on adaptive
LCD technology.
Windows Embedded Compact 7
Truly Projected Capacitive Touch Sensor that
supports multi-touch and gesturing
1GB DDR3 SDRAM
4G Fixed NAND Flash
8G microSD Flash Card
LED backlights with three intensity setting
controlled by the Automatic Light Sensor or
API
Magnesium Alloy, PC-ABD, and Nylon
materials
Spill and drop resistant
830 grams (1.8 lbs.)
16mm D, 176mm W, 292mm H (0.62 in x 6.90
in x 11.5 in)
Modular Integrated 3-Track card reader
capable of encryption at the swipe.
Charging Pins (for MICROS Tablet Multi-Unit
Charger)
Multi-function connector for Base Station (All
signals between Tablet and Base Station)
802.11 a/b/g/n Wi-Fi with WPA WPA2, TKIP,
AES support
Bluetooth V2.01
Wi-Fi/Bluetooth not available on Concessions
Tablet
Embedded Lithium Ion (21.8Wh)
Embedded Battery not available on
Concessions Tablet
5 VDC, 2.5A
120 Typical, 290 Maximum
-10°C (14°F) to 60°C (140°F)
When Charging Battery: 0°C (32°F) to 45°C
(113°F)
-25°C (-13°F) to 85°C (185°F)
FCC Class A, UL, CE, TUV, RoHS, China
RoHS
