  • Page 1 ® Oracle MICROS Tablet 720 Setup Guide E86334-02 May 2017...
  • Page 2 Oracle Corporation and its affiliates disclaim any liability for any damages caused by use of this software or hardware in dangerous applications.

  • Page 3: Table Of Contents

    Contents ................................. v Preface 1 The Oracle MICROS Tablet 720 Tablet Features ............................1-1 Technical Specifications ........................... 1-3 Software Components..........................1-4 Tablet Accessories............................. 1-5 2 Setup and Configuration Performing an Initial Setup ........................2-1 Inserting and Removing the Battery ...................... 2-1 Charging the Tablet and Battery ......................
  • Page 4 Troubleshooting the Barcode Scanner ....................6-1 Troubleshooting the MSR........................6-2 Performing a System Recovery....................... 6-2 7 Care and Handling ....................7-1 8 Regulatory and Compliance FCC Compliance ............................8-1 FCC Interference ............................8-1...

  • Page 5: Preface

    Preface The Oracle MICROS Tablet 720 is a built for purpose tablet and designed for the hospitality market. Audience This document is intended for those who will be setting up, installing, and operating the Oracle MICROS Tablet 720. It is not specific to a particular software application.

  • Page 7: The Oracle Micros Tablet 720

    The Oracle MICROS Tablet 720 The Oracle MICROS Tablet 720 features a slim yet rugged enclosure, a 7–inch TFT display powered by the Intel Atom quad-core processor, and offers optimal combinations of performance and power savings. It offers integrated Wi-Fi and Bluetooth connectivity, a magnetic stripe reader, an optional barcode scanner, and an optional RFID reader.
  • Page 8 Tablet Features Figure 1-2 The Features of the Oracle MICROS Tablet 720 — Back View Table 1-1 Input/Output Port on the Oracle MICROS Tablet 720 Feature Description A. Barcode Scanner (Optional) Captures and reads information contained in a bar code.

  • Page 9: Technical Specifications

    Technical Specifications Technical Specifications The following table contains the technical specifications for the Oracle MICROS Tablet 720. Table 1-3 Technical Specifications for the Oracle MICROS Tablet 720 Feature MICROS Tablet 720 Processor Intel Atom Quad Core, 1.33GHz Storage 64GB Flash Operating System Microsoft Windows Embedded 8.1 Industry...

  • Page 10: Software Components

    Reader/Writer Mode @ 13.56MHz Software Components The Oracle MICROS Tablet 720 comes pre-installed with the Microsoft Windows Embedded 8.1 Industry Pro or Microsoft Windows 10 IoT Enterprise operating system. The Microsoft Windows Embedded 8.1 Industry Pro operating system offers the latest Windows 8.1 innovations in security, management, and user experience, as well as the...

  • Page 11: Tablet Accessories

    Charger, or External Power Adapter. External Power Adapter Charges a single tablet with battery attached. Part Number: 7117487 4–Bay Battery Charger Charges up to 4 batteries at a time. Part Number: 7117507 Requires the C7 straight power cord. The Oracle MICROS Tablet 720 1-5...
  • Page 12 Part Number: 7117489 Requires the C7 straight power cord. Desktop Charging Cradle Charges one tablet with battery attached and one spare battery at the same time. Part Number: 7117490 Requires the C7 straight power cord. 1-6 Oracle MICROS Tablet 720 Setup Guide...
  • Page 13 Tablet Accessories Table 1-4 (Cont.) Oracle MICROS Tablet 720 Accessories Accessory Description Carrying Pouch Allows for hands-free portability. Part Number: 7117488 The Oracle MICROS Tablet 720 1-7...
  • Page 14 Tablet Accessories 1-8 Setup Guide...

  • Page 15: Setup And Configuration

    Setup and Configuration This section contains instructions for setting up and configuring the Oracle MICROS Tablet 720. Performing an Initial Setup Inserting and Removing the Battery Charging the Tablet and Battery Powering the Tablet On and Off Barcode Scanner Configuration...

  • Page 16: Charging The Tablet And Battery

    The display powers on in a few seconds. To place in standby mode and conserve power, push and quickly release the Power button. The display is turned off, but the tablet remains on. 2-2 Oracle MICROS Tablet 720 Setup Guide...

  • Page 17: Barcode Scanner Configuration

    Use precaution. This type of shutdown is only advisable for troubleshooting and not as normal operation. Barcode Scanner Configuration The Barcode Scanner is an optional configuration of the Oracle MICROS Tablet 720. It comes pre-installed and is programmed for the most common terminal and communications settings.
  • Page 18 Using the Barcode Scanner Figure 2-1 Barcode Scanner Field of View 2-4 Oracle MICROS Tablet 720 Setup Guide...

  • Page 19: Battery Performance

    Battery Performance This section contains details regarding the battery for the Oracle MICROS Tablet 720. LED Status and Behavior Battery Life and Charging Times Backup Battery LED Status and Behavior The following table describes the behavior and status of the tablet’s LED when connected and disconnected from the power supply.

  • Page 20: Battery Life And Charging Times

    Green Battery is fully charged. Battery Life and Charging Times The following table lists the charging and discharging data for the Oracle MICROS Tablet 720. The charging data pertains to all power supplies and chargers designed for the tablet. Table 3-3...

  • Page 21: Wireless Networking

    Wireless Networking The Oracle MICROS Tablet 720 is equipped with an embedded 802.11a/b/g/n WLAN adapter and Bluetooth 4.0 low energy (LE) network technology. Connecting to a Wireless Network Configuring Bluetooth Connecting to a Wireless Network The Oracle MICROS Tablet 720 contains an embedded 802.11a/b/g/n WLAN adapter equipped with a hidden custom antenna.
  • Page 22 Configuring Bluetooth Select the Bluetooth device from the list of available devices. 4-2 Oracle MICROS Tablet 720 Setup Guide...

  • Page 23: Equipment Dimensions

    Equipment Dimensions This section contains dimensions for the Oracle MICROS Tablet 720 and its accessories. Tablet 720 Dimensions 4-Bay Tablet Charger Dimensions 4-Bay Battery Charger Dimensions Tablet 720 Dimensions Figure 5-1 Oracle MICROS Tablet 720 Dimensions Equipment Dimensions 5-1...

  • Page 24: 4-Bay Tablet Charger Dimensions

    4-Bay Tablet Charger Dimensions 4-Bay Tablet Charger Dimensions Figure 5-2 Oracle MICROS Tablet 720 4-Bay Tablet Charger Dimensions 5-2 Oracle MICROS Tablet 720 Setup Guide...

  • Page 25: 4-Bay Battery Charger Dimensions

    4-Bay Battery Charger Dimensions 4-Bay Battery Charger Dimensions Figure 5-3 Oracle MICROS Tablet 720 4-Bay Battery Charger Dimensions Equipment Dimensions 5-3...
  • Page 26 4-Bay Battery Charger Dimensions 5-4 Setup Guide...

  • Page 27: Troubleshooting

    Performing a System Recovery Basic Troubleshooting The following table contains descriptions and solutions for common problems encountered with the Oracle MICROS Tablet 720. Table 6-1 Basic Troubleshooting of the Oracle MICROS Tablet 720 Problem Possible Causes Solution Tablet will not power up.

  • Page 28: Troubleshooting The Msr

    Login to My Oracle Support, download the system recovery file, and then create the recovery media: Click the Patches & Updates tab, and then search for the Oracle MICROS Tablet 720 product and applicable operating system. 6-2 Oracle MICROS Tablet 720 Setup Guide...
  • Page 29 USB flash drive. The system recovery process begins. When complete, select Y to power off or N to reboot. The tablet automatically shuts down after 3 minutes. Figure 6-1 System Recovery Process for the Oracle MICROS Tablet 720 Troubleshooting 6-3...
  • Page 30 Performing a System Recovery 6-4 Setup Guide...

  • Page 31: Care And Handling

    Care and Handling Use the following precautions when operating the Oracle MICROS Tablet 720. • Always exercise care when operating and handling the tablet. • Use a cleaner and cloth intended for use on LCD screens to clean the display screen.
  • Page 32 7-2 Setup Guide...

  • Page 33: Regulatory And Compliance

    Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult with an Oracle MICROS consultant or experienced technician for assistance. Regulatory and Compliance 8-1...
  • Page 34 FCC Interference 8-2 Setup Guide...
