Table 10-1
Feature
Case Material
Weight (/w Hard Disk and VFD Display)
Physical Dimensions
Optional Customer Displays (Series)
Cash Drawers
LAN Interface
COM Ports
USB Ports
AC Input Voltage
Input Power
Operating Temperature
Storage Temperature
MICROS PC Workstation 2010 Connectors
The figure below shows the PC Workstation 2010 modular COM ports.
Figure 10-2
(Cont.) MICROS PC Workstation 2010
MICROS PC Workstation 2010 Connectors
MICROS PC Workstation 2010 Connectors
Specifications
PC-ABS Plastic
With 12.1" LCD - 17 lbs. (7.7 Kg)
With 15 LCD - 22.7 lbs. (10.3 Kg)
The Equipment Dimensions
more information.
Pole 240x64 Graphics Capable Display with
2x20 emulation.
2 MICROS 4-Pin DIN Connectors - +12V or
+24V Jumper Selectable.
10/100 Mbps BaseT Ethernet
• 1 DB9 RS232 Serial
• 2 Modular RS232/RS422
4
Universal 90-264VAC, 47-63GHz.
46W Typical, 242W Maximum
0°C (32°F) to 45°C (113°F), 90% relative
humidity max.
-25°C (-13°F) to 80°C (176°F)
Chapter 10
section contains
10-2
