Technical Specifications

Product name
Model
Dimension
Weight
Input
Work Temp.
Effect height
Height adjstable
Effect direction
Hopper capacity
Height adjustable
HC8200 consumption rate
Interface
Control

Operation Panel

LED display area:
READY DMX
READY: Flashing means heating up, about 5min. Turns from flashing into long on, indicates that the machine is ready
to work.
DMX: Flashing shows that DMX signal is connected, light OFF means there is no DMX signal
FAULT: Light ON when error occurs
HEAT: Light ON when system is heating up
Control Button Area:
MENU: switch through setup menu. Press 3s switch to advanced interface
DOWN: parameter down
UP: parameter up
ENTER: confirm and save parameters
SPARKULAR PRO
BT71/BT72
315x290x285mm
16.5Kg
AC 220VAC-240VAC,50/60HZ; 600W Max.cascade: 5PCS;
AC 100VAC-120VAC,50/60HZ; 700W Max.cascade: 3PCS;
-20°C~50°C
HC8200 LARGE / HC8200 LARGEⅠ: 5~5.5m
Yes
Straight up
1200g
Yes
20g/min
NEUTRIK POWERCON TRUE1, 3-pin waterproof DMX connectors
DMX
FAULT HEAT
