Switch
S1
S2
S3
S4
8

ADS1256EVM-PDK Kit Operation

This section provides information on using the ADS1256EVM-PDK, including setup, program installation,
and program usage. To prepare to evaluate the ADS1256 with the ADS1256EVM-PDK, complete the
following steps:
Step 1. Install the ADCPro software (if not already installed).
Step 2. Install the ADS1256EVM-PDK EVM plug-in software.
Step 3. Set up the ADS1256EVM-PDK.
Step 4. Connect a proper power supply or ac adapter.
Step 5. Complete the NI-VISA™ USB driver installation process.
Step 6. Run the ADCPro software.
Step 7. Complete the Microsoft Windows USB driver installation process.
Each task is described in the subsequent sections of this document.
8.1 Installing the ADCPro Software
Do not connect the ADS1256EVM-PDK before installing the software. Failure to
observe this may cause Microsoft Windows to not recognize the ADS1256EVM-
PDK.
The latest software is available from Texas Instruments' website at
PDK. Download the ADCPro Installer from the
to the ADCPro User Guide
To install the ADS1256EVM-PDK plug-in, download and run the file: ADS1256evm-pdk-plug-in-1.0.0.exe
from the ADS1256EVM-PDK product folder
version releases). Double-click the file to run it; then follow the instructions shown.
Installation for the ADS1256EVM plug-in should be relatively straightforward. The plug-in comes as an
executable file. Once started, the program leads the user through the screens shown in
Figure 11.
SBAU090E – November 2003 – Revised November 2018
Submit Documentation Feedback
Table 11. Default Switch Positions
Default Position
Left
Left
Up
Left
CAUTION
ADCPro product information page
for instructions on installing and using ADCPro.
(1.0.0 is the version number, and increments with software
Copyright © 2003–2018, Texas Instruments Incorporated
ADS1256EVM-PDK Kit Operation
Switch Description
AIN0-1 Input Select Switch
AIN2-3 Input Select Switch
Reference Input Select
System Clock Select Switch
http://www.ti.com/tool/ADS1256EVM-
on the TI website. Refer
ADS1256EVM and ADS1256EVM-PDK
Figure 8 through
