Board Marking
EST
OBH
OBL
In the EXT position, J1 pins 18 and 20 are connected to the ADS1256 reference input.
In the OBH position, the analog power supply is connected to the positive reference input, and the
negative reference input is connected to the output of the onboard reference.
In the OBL position, the onboard reference output is connected to the ADS1256 positive reference input
pin, and the negative reference input pin is grounded.
Both OBH and OBL provide a +2.5V reference to the ADS1256. The OBL position corresponds to the
standard method to connect a reference to the ADS1256, and should be used for most measurements.
The OBH position is useful for testing the reference input common-mode sensitivity, which can be
important for ratiometric connections.
6 Clock Source
As shown in Figure
will be provided to the ADS1256.
SBAU090E – November 2003 – Revised November 2018
Submit Documentation Feedback
Table 6. Reference Input Select Switch
Switch Position Input Source
Down
Middle Onboard, high common-
Up Onboard, low common-
5, switch S4 selects which of the two available clock sources on the ADS1256EVM
Table 7 summarizes the positions of the switch.
Figure 5. Switch S4
Table 7. System Clock Select Switch
Board Marking Switch Position
XTAL
EXT
Copyright © 2003–2018, Texas Instruments Incorporated
VRP Connection
External J1.20
AVDD
mode
+2.5V
mode
Clock Source
Left Onboard 7.68MHz
crystal
Right External (J2 pin 17)
ADS1256EVM and ADS1256EVM-PDK
Clock Source
VRN Connection
J1.18
+2.5V
AGND
