Installing the Wall Mounting Kit
1. Remove the
four mounting
screws from
the underside
of the unit.
Do
not
disassemble
the unit.
2. Install the wall
mounting ears
to the unit
using the
screws
removed in
Step 2
3. The unit is
ready for wall
mounting.
4. Use M3 or #4
screws (not
included) for
attachment to
suitable surface
iboot-dc_v181024e
DIN Rail Mounting
1. Install the
Wall
Mounting Kit
as shown.
2. Install the
DIN rail clips
using the
four screws
provided.
3. Ready for
DIN rail
mounting.
iBoot-DC
Page 5
