6.0 Service

Warning! Any unauthorised changes to the product is not
allowed! Only original spare parts may be used!
6.1 Replacing the baffl e/defl ectors
Fig. 17
B
1. Lift the baffl e (fi g. 17A) up carefully.
2. Remove the pins (fi g. 17B).
3. Ease the baffl e out.
Fig. 18
B
1. Lift the exhaust defl ector (fi g. 18A) up carefully.
2. Remove the pins (fi g. 18B).
3. Ease the exhaust defl ector out.
14
A
A
6.2 Replacing the burn plates/inner
bottom
Fig. 19
B
1. Take out the baffl e/exhaust defl ector (see 6.1 - Replacing
the baffl e/exhaust defl ectors)
2. Take out the side burn plates (fi g. 19A).
3. Take out the rear burn plates (fi g. 19B).
Fig. 20
4. Lift out the ash grate (fi g. 20A) and inner bottom plate
(fi g. 20B).
5. When refi tting, follow the same procedure in reverse order.
A
A
B
