Service Functions
9.3 Resetting the Power Reducer Box
The Power Reducer Box can be reset using a reset button. The hole for the reset button is found on the
rear panel of the Power Reducer Box under the upper left foot.
The Power Reducer Box must be on when activating the reset button.
1. Use a pointed object (such as a paper clip) to
activate the reset button through the hole. Depending
on the duration, the actions listed in the table below
will be performed.
Time
< 1 second
1 - 5 seconds
5 - 15 seconds
☑ The Power Reducer Box is reset.
By interrupting the power supply, you can restart the device without resetting the passwords or the
settings. See section 9.2 "Stopping the Power Reducer Box" (page 41).
42 REDUCERBOX-TEN100412
Resetting of the network settings
Resetting of the network settings and passwords
Resetting of all settings of the Power Reducer Box to the factory
settings (=delivery state)
SMA Solar Technology AG
Action
