Operation
7.5 Context Menu
Button
WebBox registration
Status configuration
Password settings
7.6 Device Status
On the "Status" page an overview of the current status of the PV system is given in the upper area. The
following information is shown:

Device status

Operating mode
Setpoint (set)
Setpoint (current)
Status of the input ports
Display of the current status of the Power Reducer Box
The device status is also displayed on the login page of the Power Reducer Box.
In the lower area, all of the Sunny WebBox devices registered to the Power Reducer Box are listed
with their current communication status. A Sunny WebBox can have the following statuses:
Symbol Status
Ok
Unknown
Failure
28 REDUCERBOX-TEN100412
This menu item opens the "WebBox registration" page
(see section 7.8 "WebBox Registration" (page 31)).
This menu item opens the "Status configuration" page
(see section 7.9 "Configuring the System States" (page 33)).
This menu item opens the "Password settings" page.
The device status displays which overall status the Power Reducer
Box is in.
The operating mode displays which parameter the Power Reducer
Box is currently implementing.
The Setpoint (set) displays which values have been configured in
the Power Reducer Boy for the parameter.
The Setpoint (current) displays which values are currently being
implemented.
The status shows the current incoming signal of the radio ripple
control receiver. K1 to K4 relate to the respective connected
relays. If no signal is incoming, the value "Open" is displayed.
Communication between Power Reducer Box and Sunny WebBox
is functioning correctly.
The communication status of the Sunny WebBox is currently
unknown.
There is a communication failure between the Power Reducer Box
and the Sunny WebBox.
SMA Solar Technology AG
Function
Description
