7.6.1 Updating the Device Status
Automatic updating of the page contents
The page contents are updated automatically every 30 seconds.
You can update the device status manually:
1. Select "Status" in the main menu.
2. Select [Update].
☑ The device status will be updated.
7.7 Events
All events of the Power Reducer Box, such as change to status or fault in communication, are logged
and displayed on the "Events" page. All events are recorded in the internal memory. Once the internal
memory has reached its capacity, the oldest events will be written over. In addition you have the
possibility to save the events onto an SD card.
7.7.1 Filtering and Displaying Events
1. Select "Events" in the main menu.
☑ The events of the current day are displayed.
2. If necessary, filter the events. For this, a checkmark must be placed in the relevant field. Multiple
selection is possible. The following filter settings are possible:
– Status change
– Info
– Warning
– Disturbance
– Error
3. Select time period.
4. Select [Update].
☑ The events in the desired time period are displayed.
In addition events can be downloaded directly (see section 7.7.2 ) or saved additionally onto an SD
card (see section 7.7.3 ).
