3 Unpacking
3.1 Scope of Delivery
Check the delivery for completeness and any visible external damage. Please contact your dealer if
the delivery is not complete or you find any damage.
Position Quantity
A 1
B 1
C 1
D 1
E 1
F 2
G 2
H 1
I 1
Technical Description
Power Reducer Box
Plug-in power supply with four adaptors
Red Ethernet cable (patch cable)
Blue Ethernet cable (crossover cable)
Screwdriver
Screws
Wall anchor
Technical description with drilling template and compatibility list
Pre-assembled cable (length 2.5 m) with 7 pole socket
(for the connection of the radio ripple control receiver)
Designation
REDUCERBOX-TEN100412
