Do not exceed the maximum duty cycle of 2 minutes. Observe a subsequent break of at least
18 minutes by all means.
3.9

Second controller (optional as accessory)

The nursing care bed can optionally be equipped with an additional controller.
For this purpose a second control box is mounted in the bed, which is connected to socket
2 of the controller. The hand control in socket 1 and the second controller in socket 2 are
plugged into this second control box. Sockets 3, 4 and 5 remain unassigned and are
equipped with a blind plug.
Operation:
To control the nursing care bed with the control panel, the keys must be released by press-
ing the "START" key (1). Now all functions can be executed that you can also find on the
hand control. After adjusting the nursing care bed, you can press the "STOP" button to
activate the key lock immediately, otherwise it will be activated automatically after some
time of non-use.
Locking of functions:
You can use the second control panel to lock individual functions. To do this, press the key
with the symbolic lock (3). Now you can select individual functions. The function is not
disabled when the respective control lamp is lit. If the respective control lamp does not
light up, the function is disabled. These functions are then disabled on the control panel
and on the hand control. After you have locked all the necessary keys, you can confirm
your selection by pressing the "START" or "STOP" key. The settings remain saved.
ATTENTION: If certain functions have been locked on the hand control, they are not
locked on the second controller. These functions must be locked separately here.
