BOCK practico alu plus Assembly And Operation Manual page 13

(*) Depending on the length of the lying surface. The single post at the head and leg end is optional. The
dimension in brackets is optional.
Legend
A: Distance between the head part and the side rail
B: Height 1 of side rail
C: Height 2 of side rail
D: Width 1 of the side rail
E: Distance between the elements within the side rail
F: Distance between the divided side rails
G: Distance between the lying surface and the upper edge of the side rail
H: Height of the top edge of the side rail above the mattress without compression
I: Thickness of the mattress for the intended use
J: Width 2 of the side rail
K: Smallest dimension between side rail and lying surface (or the panel, if any)
L: Distance between the foot part and the side rail
Item numbers
Designation
Fig. 1: Continuous wood side rail
Wooden side rail (two bars)
Fig. 2: Telescopic wooden side rail, solo post in the middle
Wooden side rail (two bars)
Fig. 3: Telescopic wooden side rail, double post in the middle
Wooden side rail long head part (two bars)
Wooden side rail short foot end (two bars)
Use only original Bock side rails, which are available as accessories for every nursing care beds.
Use only technically flawless and non-damaged side rails with the permissible gap dimensions.
Make sure that the side rails are engaged securely.
Before installation of the side rail and each new use, inspect all mechanical parts on the bed
frame, and all parts of the side rails, and all parts which secure the side rails, for any possible
damages.
The operation of the side rail should be done with great care. Fingers can be quickly pinched
between the longitudinal pieces.
Hazard note from Bock
13
item no.
91703
91868
91704
91705
