13.3. Functions of Infrared Sample Codes

The below functions can be implemented using infrared sample codes provided by
Espressif Systems:
Functions of infrared transmitting and receiving can be invoked in the initialization
•
process, and a 4s loop timer can be configured to transmit infrared remote control
codes.
Check the ring buffer of infrared remote control codes simultaneously. If there is any
•
data in the queue, it will be printed out.
If any carrier waveform in comply with NEC infrared remote control protocol is
•
received by the state machine of infrared receiver, the instruction fields will be stored
in the ring buffer of infrared receiving codes.
