Assembly
2. Wings
7
Picture 7:
Now push the wings together completely.
Note: When installing and connecting the receiver, make sure that the servos are not blocked by cables. Secure the receiver and the
controller in the model against slipping with Velcro tape in a suitable place. Observe the connection diagram and operating
instructions of the remote control system manufacturer.
10
I N S T R U C T I O N S A N D U S E R M A N U A L
8
Picture 8:
Secure the second wing with the locking screw on the underside
of the wing on the carbon fibre tube.
Tighten the screw with feeling, but firmly.
