Operating Instructions
BLUE ARROW
NANO LOOP RTF
2.4 GHz
No. S2531

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLUE ARROW NANO LOOP 2.4 GHz and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ROBBE BLUE ARROW NANO LOOP 2.4 GHz

Summary of Contents for ROBBE BLUE ARROW NANO LOOP 2.4 GHz

  • Page 1 Operating Instructions BLUE ARROW NANO LOOP RTF 2.4 GHz No. S2531...

  • Page 2: Table Of Contents

    Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Explanation of specialist terms: Contents Page Explanation of specialist terms / Contents Climb and descent ("Throttle/pitch"): This controls the Safety Notes 3, 4 model's climb and descent. Set contents / Specification / Recommended accessories Yaw: The model's movement around the vertical axis;...

  • Page 3: Safety Notes

    Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Be sure to read these Safety Notes before you attempt to Do not stand close to the hazard area around rotating parts fly your model. Always keep to the procedures and settings when an electric motor is connected to the flight battery.
  • Page 4 Liability Exclusion • Never fly over or towards spectators or other pilots, and robbe Modellsport is unable to ensure that you observe the as- maintain a safe distance from them at all times. sembly and operating instructions, or the conditions and methods • Never endanger people or animals.
  • Page 5 Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Dear customer, Congratulations on choosing a factory-assembled mo- del helicopter from our range. Many thanks for placing your trust in us. The model can be completed and made ready to fly very quickly.

  • Page 6: Transmitter Description Mode 1 + 3

    Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Transmitter description Mode 1 + 3 Aerial A = Mounting screws. B = Battery compartment C = Buddy Box connection D = unused Neckstrap fixing Mode 1+3: Motor speed trimming Mode 1 + 3: Elevator trimming...

  • Page 7: Transmitter Description Mode 2 +4

    Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Transmitter description Mode 2 + 4 Aerial A = Mounting screws. B = Battery compartment C = Buddy Box connection D = unused Neckstrap fixing Pitch-axis trim Throttle trim Joystick Mode 2:...

  • Page 8: Changing The Transmitter Throttle Stick

    Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Changing the transmitter throttle stick front 1. Open the battery box cover. Remove the black propeller battery retainer, unplug the battery plug from the socket in the transmitter. 2. Remove the transmitter rear cover. This is done by removing the six retaining screws on the rear face.

  • Page 9: Important Assembly Steps Before The First Flight

    Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Important assembly steps before the fi rst fl ight Receiver outputs Fitting the canopy: Monitor LED Fit the canopy before the fi rst fl ight. On the lower edge of the canopy there are four cut-outs.

  • Page 10: Transmitter Lcd Display

    Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Transmitter LCD display Transmitter settings Transmitter voltage display Mode display Elevator function Settings display Roll function Motor speed Elevator trimming ELEVATOR-Reverse-setting Yaw function Throttle trimming Click on "ENT". Use the select button for transmitter setting to Buzzer "ELEV".

  • Page 11: Transmitter Settings

    Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Transmitter settings Transmitter settings Throttle-Reverse-setting BUZZER-setting 3. Click on "ENT". Use the transmitter settings select button for 3. Click on "ENT". Use the transmitter settings button select "BUZZ". "THRO". The "THRO" and "NOR" fl ash. Select between NOR or The "BUZZ"...

  • Page 12: Charging The Flight Battery

    LIABILITY EXCLUSION cool down to ambient temperature. Charge the battery only using the Since robbe Modellsport is not in a position to monitor the charger included in the set; do not use any other charger. The char- handling of these batteries, we expressly deny all liability and ger should only be used to charge the battery included in the set.
  • Page 13 Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 1. Normal mode Open the battery compartment and insert the battery. Close the battery com- partment. Set the throttle stick to the lowest position, switch the transmitter on (Fig 1) and fit a charged battery into the holder in the BLUE ARROW NANO LOOP and connect (Fig 2).
  • Page 14 Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Trim settings Mode 1 Trim settings Mode 2 Throttle trim: Throttle trim: If the rotors starts to move without you If the rotors starts to move without you touching the throttle stick, or does not...
  • Page 15 Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Trim settings Mode 3 Trim settings Mode 4 Throttle trim: Throttle trim: If the rotors starts to move without you If the rotors starts to move without you touching the throttle stick, or does not...
  • Page 16 Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Controlling the model in Mode 1 Controlling the model in Mode 2 Lift off: Landing: Lift off: Landing: Yaw left: Yaw right: Yaw left: Yaw right: Pitch forward: Pitch back: Pitch forward:...
  • Page 17 Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Controlling the model in Mode 3 Controlling the model in Mode 4 Lift off: Landing: Lift off: Landing: Yaw left: Yaw right: Yaw left: Yaw right: Pitch forward: Pitch back: Pitch forward:...
  • Page 18 Operating Instructions,BLUE ARROW NANO LOOP 2.4 GHz No. S2531 Important Notes The first few flights Take-off: Raise the rotor speed slowly and steadily until the mo- Ideally the first flight should take place in a large indoor space del hovers at eye-level. Trim the model out so that it has a stable devoid of obstructions.

  • Page 19: Spare Parts

    Spare parts list BLUE ARROW NANO LOOP RTF 2.4 GHZ No. S2531 Spare parts list BLUE ARROW NANO LOOP RTF Order No. Description S2531001 Propeller 4 pcs. S2531002 Canopy S2531003 Main frame S2531004 Motor mountings 4 pieces S2531005 E-Motor right hand with arm S2531006 E-Motor left hand with arm S2531001...
  • Page 20 Modellsport Beteiligungs GmbH Gießen / HRB 5793 Managing Directors: E. Dörr Errors and technical modifications reserved Copyright robbe-Modellsport 2012 Duplication and copying of the text, in whole or in part, is only permitted with the prior written approval of robbe-Modellsport GmbH & Co. KG...
