computer radio control system
The procedure is as follows:
1.
Connect the JETIBOX with the connecting cable to the Ext.
receiver output .
2.
Switch on the receiver - (connect a proper voltage supply to the
receiver).
3.
The receiver menu appears on the JETIBOX display. Select the
„Pairing" menu item (push the right arrow button once from the
main receiver display) and then push the upward button. You now
have a period of 60 seconds to bind the receiver. After the 60
seconds elapse the receiver returns to setup mode and the binding
process must be repeated by starting again from step 3.
If the binding process between receiver and transmitter was
unsuccessful, try again.
You may bind an arbitrary number of receivers to one transmitter.
The receiver, however, can only be bound to one transmitter, i. e. the
receiver is only bound to the most recently bound transmitter.

3.5 Range test

By range testing, you verify the correct operation of the transmitter
and receiver. You should perform a range test before your first flight
of each flight day, or if there are any doubts about the function of
the transmitter or receiver. In the range test mode, the transmit
power is reduced to 10%. When testing range, place both the model
and transmitter at a height of at least 80cm (3ft) from the ground. A
properly operating transmitter and receiver should reliably control
www.modellmarkt
www.modellmarkt
the model at a distance of at least 50 meters (or 50 yards) in the test
12
EN
