5. Menu Operations

[1] PICTURE

PICTURE 같이
BRIGHT
CONTRAST
CHROMA
APERTURE
KNOB LOCK
3DLUT LOAD
3DLUT SYNC
3DLUT IMPORT 1
3DLUT IMPORT 2
3DLUT IMPORT 3
• BRIGHTNESS
- Used to set the brightness(=offset) level
from -100 to 100.
# Brightness can be adjusted by using the
Knob on the top of the monitor.
• CONTRAST
- Used to set the contrast(gain) level from -100
to 100.
# Contrast can be adjusted by using the
Knob on the top of the monitor.
• CHROMA
- Used to set the saturation level from -50 to 50.
# Chroma can be adjusted by using the Knob
on the top of the monitor.
• APERTURE
- Used to set the sharpness level from -12 to
12.
# Aperture can be adjusted by using
the Knob on the top of the monitor.
• KNOB LOCK
- Locks the Knob control.
F-7H
+90
+90
+90
+90
UNLOCK
REC 709
SYNCHRONIZATION
NONE01
NONE01
NONE01
• 3DLUT LOAD
- Used to apply the internally stored 3DLUT.
- Maximum 3 x 3DLUT files can be stored.
- The file name can be set up to 20
characters including the extension.
• 3DLUT SYNC
- Used to load a list of available 3DLUT files
currently stored in the FLASH MEMORY.
- Available 3DLUT formats are Cube, GV Lut,
Quantel, Davinci and AssScratch.
- Available sizes of the 3DLUT are 17 or 33.
• 3DLUT IMPORT 1/2/3
- Used to save the 3DLUT stored in the
external memory to the internal memory
1/2/3 area.
- Once saved, the 3DLUT can be maintained
even when the power is turned ON/OFF.
- The file name can be set up to 20
characters including the extension.
