Color - TVLogic F-7H Operation Manual

5. Menu Operations

[2] COLOR

COLOR같이
STANDARD
VIDEO RANGE
PEAK LUMINANCE
BLACK LEVEL
COLOR GAMUT
COLOR TEMP
EOTF
LOCAL DIMMING
EETF
HLG SG
SG
CAM LUT
CAM LUT THR
• STANDARD
- Used to select the color and dynamic rage
of the screen.
- Available options are HD, UHD, DCI-P3, PQ,
HLG, SLog3 and User1/2/3.
# Activates only in the User1/2/3 mode.
• VIDEO RANGE
- Used to select the range of digital video
signal.
* Full Range : Input signal 0~255 (8bit),
0~1023 (10bit) (When connecting the PC)
* Narrow : Input signal Y': 16~235, CbCr:
16~240 (8bit)/ Y': 64~940, CbCr: 64-960
(10bit)
• PEAK LUMINANCE
- Used to select the Peak Luminance of the
monitor.
- Available options are 100, 200, 300, 400,
500, 600, 700, 800, 900, 1000, 2000, 4000
and 10000.
- Activates only in the User1/2/3 mode.
F-7H
UHD
NARROW
100
0.001
BT.2020
6500K
2.4
OFF
OFF
OFF
OFF
OFF
PAGE (1/2)
• BLACK LEVEL
- The minimum black level of the video signal
can be set differently depending on the
performance of the monitor or the lighting
environment. For example, the lowest
luminance that the F-7H can display is
0.002, but it is necessary to adjust the offset
level to about 0.2nit when using under
bright light.
- At this time, when the black level is set to
0.2, dark gradations below 0.2 nit are
expressed without crushing.
- Activates only in the User1/2/3 mode.
• COLOR GAMUT
- Used to select the standard color gamut.
- Available options are BT.709, DCI-P3,
BT.2020 and Native.
# The submenus may be activated in the
User1/2/3 mode only.
• COLOR TEMP
- Controls the color temperature.
- Available options are 6500K, 9300K and User.
# The submenus may be activated in the
User1/2/3 mode only.
• EOTF
- Electrophotic conversion Functions(ex:
Gamma or HDR curve).
- Available modes are 2.2, 2.4, 2.6, PQ, HLG
and SLOG3.
# The submenus may be activated in the
User1/2/3 mode only.
• LOCAL DIMMING
- Used to set the Local Dimming Backlight
mode.
